Omada L2+ Managed Switch
Use the console port to access the switch. When using the console port, start the terminal emulation
■
program (such as the Hyper Terminal) on the PC and configure the terminal emulation program as
follows:
Baud Rate
38400 bps
For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on
the download center of our official website: https://www.tp-link.com/download-center.html
Note:
For certain devices, you may need to change the password the first time you log in, which will
better protect your network and devices.
4.3

Controller Mode

Controller Mode applies to the large scale network with mass devices. All devices can be centrally
configured and monitored via Omada Hardware Controller or Omada Software Controller.
Note:
Before the following configurations, make sure the switch can access the internet. When using
Omada Software/Hardware Controller, make sure the switch and the controller are in the same
subnet. Typically, the switch obtains IP address from the DHCP server. You can check the
switch's IP address on the DHCP server.
Via Omada Hardware Controller
■
Omada Hardware Controller is a good alternative if you have no spare PC to keep running Omada
Software Controller in the network. It needs to be purchased additionally. Follow the steps below to
configure the Omada Hardware Controller.
Figure 4-2 Manage the network via Omada Software/Hardware Controller
Omada Hardware Controller
24 Configuration
Data Bits Parity
8
EAP
Stop Bits
None
Router
Switch
EAP
Clients
Flow Control
1 None
EAP
