Omada L2+ Managed Switch
For SG3428X
LED
PWR
SYS
Link/Act
1000Mbps
Port 25–28
For SG3428XF
PWR1* PWR2
Green On Off
Green On Yellow On**
Off Green On
Off Off
LED Indication
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
Green: All the fans work properly.
FAN
Yellow: Not all the fans work properly.
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
Port 1-24 Yellow On: Running at 100 Mbps, but no activity.
Yellow Flashing: Running at 100 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
10 Introduction
Indication
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
Flashing: The switch works properly.
On or Off: The switch works improperly.
On: A device is linked to the port but no activity.
Off: No device is linked to the corresponding port.
Flashing: Transmitting or receiving data.
On: Running at 1000 Mbps.
Off: Running at 10/100 Mbps or no device is linked to the port.
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Indication
The switch is powered by PWR1.
PWR2 is disconnected or it works improperly.
The switch is powered by PWR1.
PWR1 and PWR2 are connected.*
The switch is powered by PWR2.
PWR1 is disconnected or it works improperly.
The switch is powered off or both PWR1 and PWR2 work
improperly.
