CDN DTP572 Quick Start Manual page 3

b. LO indicates that the temperature is
lower than -58°F (-50°C).
3. ERR is displayed when there is an open circuit
or short. Restart the thermometer. If the error
message remains, please contact CDN for
further assistance.
Note: Clean the thermometer probe before each use.
Important: DO NOT LEAVE THERMOMETER CASE IN
HOT OVEN. IT IS NOT HEAT RESISTANT. DO NOT USE
PROBE IN MICROWAVE OVENS.
Important: ONLY THE PROBE CAN BE SUBMERGED IN
LIQUID. THE PROBE/SENSOR CABLE CONNECTION IS
NOT WATERPROOF.
Note on Induction Cooktops:
magnetic field may interfere with digital thermometers. If
this happens, briefly turn off the induction cooktop to get a
digital thermometer reading or use a dial thermometer.
Tip:
Meat should be allowed to "rest" for 10 to 15 minutes
after it is removed from oven. This allows time for the
meat's internal temperature to stabilize and the juices to
redistribute. This will result in a roast that is both juicier and
easier to carve.
CARE OF YOUR PRODUCT
• Do not submerge any part of the thermometer
in water.
• Wipe clean with a damp cloth.
• Store the thermometer at room temperature
between 14 to 140°F (-10 to +60°C), 10 to 95% RH.
PRECAUTIONS
• Always wear a heat resistant glove to touch the
stainless steel probe or sensor cable during or just
after cooking. Do not touch with bare hands.
• Keep the stainless steel probes and sensor cables
away from children.
• Clean the probe and dry thoroughly after use.
• Do not clean the unit with abrasive or corrosive
compound, which may scratch the plastic and
corrode the electronic circuits.
• Do not subject the unit to excessive force shock,
dust, temperature or humidity, which may result in
malfunction, shorter electronic life span, damaged
battery and distorted parts.
• Do not tamper with the unit's internal components.
Doing so will invalidated the warranty on the unit
and may cause unnecessary battery damage and
distorted parts.
• Do not subject the unit to excessive exposure to
direct sunlight. The unit is not waterproof
not immerse it into water or expose to heavy rain.
• Do not expose the sensor cable plug or the jack on
the case to water or any liquid, which will result in a
bad connection and faulty readings.
• To avoid deformation, do not place the unit in
The induction cooktop's
— do
extreme temperatures. Never burn the probe
directly over the fire. Do not use the probe when the
temperature is above +572°F (+300°C). Doing so will
deteriorate the wire.
• Do not use the probe in a microwave oven.
• Always read the user manual thoroughly before
operating.
SPECIFICATIONS
Measurement Range
-58 to +572°F/-50 to +300
Unit of Measure °F, °C
Resolution 1°F (1°C)
Operating Range
14 to 122°F (-10 to +50°C), 20 to
80% RH
Water Resilience
IPX5 – protected from water jets
(6.3mm nozzle) from any direction;
Probe able to be submerge in 1 inch
water for 30 minutes, not including
probe-sensor cable junction
Accuracy
32 to 212°F (0 to 100°C): ±2°F (1°C);
-4 to 30°F (-20 to -1°C), 214 to 302°F
(101 to 150°C): ±4°F (2°C); -58 to
-6°F (-50 to -21°C), 304 to 392°F
(151 to 200°C): ±8°F (4°C); 394 to
572°F (201 to 300°C): ±5%
Power Supply USB-A to USB-C cable, 19.7"/0.5 m,
black included; One 3.7V 400 mAh
built-in polymer rechargable battery
included
Product Dimensions 2.95 W x 2.95 H x 0.95 D in
(7.5 W x 7.5 H x 2.4 D cm)
Weight 1.8 oz (45 g) (including battery)
CAUTION: Avoid keeping the thermometer too close to
objects that continuously generate high heat for long
periods (i.e., hot plate). This can cause the thermometer to
overheat.
CE Note: This device could be sensitive to electrostatic
discharge. If electrostatic discharge or malfunctioning
occurs, please re-install the battery to reset this unit.
