3.2. Connection Diagram

All power terminal locations are marked directly on the product with AC power input and motor connections located at the
bottom of the unit.
3.2.1. Electrical Power Connections
Mains (1 or 3 phase)
L1/L L2/N L3
L1/L L2/N L3
U V W
VI
UI
WI
M
PE
12 | Coolvert Quick Start User Guide | Version 1.00
PE
COOLVERT
Incoming Power Connection
Additional information in section 3.2.2. on page 13
Protective Earth PE Connection
Additional information in section 3.2.2. on page 13
Isolator/Disconnect
Ensure there is at least 30 seconds between each power-on!
Fuses/Circuit Breaker
Additional information in section 3.2.2. on page 13
External EMC Filter (optional)
Additional information can be found
in the main user guide.
Shielded Motor Cable with PE Connection
