4 SET-UP AND OPERATION
4.1. Basic Checks Before Commissioning
It is vitally important to ensure that the Coolvert that you have purchased is suitable for the supply that you intend to connect it
to, as is the importance of ensuring that this is appropriate for the motor to be connected to.
The motor nameplate data needs to be entered accurately before attempting to run the motor. The format of the information
can vary depending on the technology of the motor. It is very important to ensure that the data entered is in the correct format.
A common mistake is to enter an incorrect value for the back emf of a permanent magnet motor at rated speed as it can be
written as a peak voltage, rms voltage and phase to phase voltage, line voltage and so on.
4.1.1. Access to Parameters
The drive parameters can be accessed via one of the following methods:
1. ModBus Communications
2. Optipad - Optional TFT Keypad
3. OptiTools - Drive Setup Software
4. Optistick Smart - Bluetooth communications
4.1.2. Motor Type and Control Mode
Par. Modbus Description
Address
5-01
501 Motor Control Mode – select according to the motor
connected to the drive:
0: BLDC Vector Speed Control
1: Permanent Magnet Vector Speed Control
2: Induction Motor Vector Speed Control (CT)
3: Induction Motor Vector Speed Control (VT)
4: Induction Motor V/F
5: Synchronous Reluctance Vector Speed Control
6: LSPM Speed Control
4.1.3. Motor Name-plate Data
Par. Modbus Description
Address
1-07
107 Motor Rated Voltage (phase-to phase rms) OR
Back EMF at Rated Speed for permanent magnet motor
types (phase to phase rms)
1-08
108 Motor Rated Current (nominal)
1-09
109 Motor Rated Frequency at Rated Speed (nominal)
1-10
1 10 Motor Rated Speed at Rated Frequency
7-03
703 Motor Stator Resistance (Rs)
This is the motor phase to phase resistance value in ohms.
7-04
704 Motor Stator Inductance (Lsd)
For induction motors: phase stator inductance value.
For permanent magnet motors: phase d-axis stator
inductance in Henry (H).
7-05
705 Motor Stator Inductance (Lsq)
For permanent magnet motors : phase d-axis stator
inductance in Henry (H).
