Fault No. Description
Code
 29 Safety circuit momentarily
opened during drive
running
Slow rising edge on 24V
supply
Safety input circuit error
p  31 Locked Rotor
 40 Measured motor stator
resistance varies between
phases

41 Measured motor stator
resistance is too large
 42 Measured motor
inductance is too low

43 Measured motor
inductance is too large

44 Measured motor parameters
are not convergent

49 Motor output phase loss

50 Modbus comms loss fault

5.2. Status LED Indication

Two LEDs are used to indicate the drive status as follows:
Drive Status
Stop
Inhibit
Running
Crankcase Heating Active
Standby
Trip / Fault
Internal Comms Loss
Oil Return Active
Optistick Transfer Pass
Optistick Transfer Fail
Optistick Fail Other
Oil Return Active
DSP Firmware Upgrade
IO Firmware Upgrade
20 | Coolvert Quick Start User Guide | Version 1.00
Suggested Remedy
Check the wiring of the STO circuit and any switches or devices within that
circuit. Ensure that any intermediate devices are not activating momentarily
during drive operation.
Can happen if an external 24V supply is used and the voltage ramps up slowly on
power-up. Could also happen if the drive 24V rail is overloaded and collapses
momentarily, check the loading of the 24V rail and all control connections.
Contact the supplier of the drive for further advice
A speed error has been detected (Locked Rotor)
Check the motor wiring, disconnect the drive and measure the phase to
phase resistance from the motor cable
Check the motor wiring, disconnect the drive and measure the phase to
phase resistance from the motor cable and refer to motor datasheet
Check the motor wiring
Check the motor wiring
Check the motor wiring
Check the motor wiring
Check the Modbus wiring, ensure that the 0V common is used, ensure that
the communication wiring is kept away from any power wiring
LED 1 Status
Green
Slow flashing
Slow Flashing
Constant On
Slow Flashing
Constant On
Off
Off
Constant On
Fast Flashing 2s
Off
Off
Constant On
All three LEDs lights up in order (Green->Yellow->Red->Yellow...)
All LEDs on with weak light
Red
Off
Off
Off Slow flashing if in overload
Off
Off
Constant On
Blink every 3s
Off
Off
Fast Flashing 5s
Off
Off
www.invertekdrives.com
LED 2 Status
Yellow
Off
Slow Flashing alternate
Constant On
Blink every 3s
Off
Off
Fast Flashing Yellow
Off
Off
Fast Flashing 5s
Constant On
