- Page 1 USER MANUAL ENGLISH Volano GU10 Track Light Product code: A0320019 – White housing A0320020 – Black housing Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Volano GU10 Track Light Preface Thank you for purchasing this Artecta product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Volano GU10 Track Light Table of contents Table of contents ................................ 2 Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety .................................. -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Artecta Volano GU10 Track Light (including track adapter, not including light source) ● User manual Fig. 01 Intended Use This device is intended for use as a spotlight. -
Page 5: Symbols And Signal Words
Volano GU10 Track Light Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER serious injury or death. -
Page 6: Safety
Volano GU10 Track Light Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children For adult use only. -
Page 7: Requirements For The User
Volano GU10 Track Light Requirements for the User This product may be used by ordinary persons. Maintenance may be carried out by ordinary persons. Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite dealer for more information. -
Page 8: Description Of The Device
Description of the Device The Artecta Volano GU10 Track Light has a GU10 socket. It can be fitted with any GU10 LED or halogen light bulb of up to 50 W. It Is suitable for illumination of residential and commercial buildings. -
Page 9: Product Specifications
Volano GU10 Track Light Product Specifications Model: Volano GU10 Track Light Movement: Track adapter: Tilt range: 0–90° Power connection: 100–240 V AC 50–60 Hz Turning range: 0–350° Phases: Optics: Construction: Light source: Not included IP rating: IP20 Light socket: GU10 Housing: Aluminum Compatibility:... -
Page 10: Installation And Deinstallation
Volano GU10 Track Light Installation and Deinstallation Safety Instructions WARNING Incorrect installation and deinstallation can cause serious injuries and damage of property. Installation and deinstallation of the device must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning electrical installations in buildings and working at heights. -
Page 11: Mounting
Volano GU10 Track Light Fig. 04 Fig. 05 Mounting The device can be mounted only to a 3-phase track system. CAUTION Restrict access under the work area during mounting. To mount the device, follow the steps below: 01) Disconnect the track system from the power supply. 02) Make sure that the circuit selector (03) is in OFF position and the track lock (02) is in unlocked position, as shown in Fig. - Page 12 Volano GU10 Track Light 04) Insert the track adapter (01) in the track and push it until it snaps into place. 05) Turn the track lock (02) clockwise to lock the device in the track, as shown in Fig. 09. Fig.
-
Page 13: Dismounting
Volano GU10 Track Light Dismounting CAUTION Restrict access under the work area during dismounting. To dismount the device, follow the steps below: 01) Disconnect the track system from the power supply. 02) Let the device cool down before dismounting. 03) Set the circuit selector (03) in OFF position, as shown in Fig. 12. Fig. -
Page 14: Direction Adjustment
Volano GU10 Track Light Direction Adjustment To adjust the angle of the device and the direction of the beam: ● Move the track head (05) around the pivot connector (04) to adjust the vertical position of the track head (05). The adjustment range is 0–90°. ●... -
Page 15: Troubleshooting
Volano GU10 Track Light Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 16: Maintenance
Volano GU10 Track Light Maintenance Preventive Maintenance Attention Before use, examine the device visually for any defects. Basic Cleaning Instructions To clean the device, follow the steps below: Disconnect the device from the electrical power supply. Allow the device to cool down for at least 15 minutes. Remove the dust collected on the external surface with dry compressed air and a soft brush. -
Page 17: Disposal
Volano GU10 Track Light Disposal Correct disposal of this product Waste Electrical and Electronic Equipment This symbol on the product, its packaging or documents indicates that the product shall not be treated as household waste. Dispose of this product by handing it to the respective collection point for recycling of electrical and electronic equipment. - Page 18 Volano GU10 Track Light Product code: A0320019 / A0320020...
- Page 19 Volano GU10 Track Light Product code: A0320019 / A0320020...
- Page 20 ©2023 Artecta...
