Summary of Contents for Artecta Aviano 30 CCT
- Page 1 USER MANUAL ENGLISH Aviano 30 CCT Product code: A0720117 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Aviano 30 CCT Preface Thank you for purchasing this Artecta product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Aviano 30 CCT Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Product Lifespan ..............................3 LEDs Lifespan ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety .................................. -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Artecta Aviano 30 CCT with fixed Schuko power cable (6 m) ● User manual Fig. 01 Intended Use This device is intended for professional use as an outdoor flood light. -
Page 5: Symbols And Signal Words
Aviano 30 CCT Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 6: Safety
Aviano 30 CCT Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 7 Aviano 30 CCT Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device. ● Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the required power consumption of the device.
-
Page 8: Requirements For The User
Aviano 30 CCT Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ● The safety devices are not damaged. -
Page 9: Description Of The Device
Description of the Device The Artecta Aviano 30 CCT is a 30 W LED floodlight with a 110° beam angle and a color temperature switch. The device can be installed with a clamp or can be mounted to a wooden or concrete wall. -
Page 10: Product Specifications
Aviano 30 CCT Product Specifications Model: Aviano 30 CCT Electrical: Input voltage: 220–240 V AC, 50/60 Hz Power consumption: 33 W Physical: Dimensions: 221 x 47 x 190 mm (LxWxH) Weight: 1,5 kg Optics: Light source: 72 x WW/NW/CW (0,4 W) LEDs... -
Page 11: Installation And Operation
Aviano 30 CCT Installation and Operation Safety Instructions WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. -
Page 12: Mounting
Aviano 30 CCT Mounting The device can be mounted to a truss or other rigging structure in any orientation or can be mounted to a wall. Make sure that all loads are within the pre-determined limits of the supporting structure. -
Page 13: Installation On A Wall
Aviano 30 CCT Installation on a Wall To install the device, follow the steps below: 01) Turn the 2 adjustment screws (01) counterclockwise to loosen them (Fig. 07). 02) Remove the 2 adjustment screws (01). The device and the mounting bracket (03) will disconnect. -
Page 14: Drilling Into Wood
Aviano 30 CCT 08) Insert the 2 adjustment screws (01) to connect the device to the mounting bracket (03). 09) Turn the 2 adjustment screws (01) clockwise to tighten them (Fig. 11). Fig. 11 Drilling into Wood If you drill into wood, use hardwood drill bits. Predrill before inserting screws, to remove drill dust and to avoid damaging of the wood. -
Page 15: Angle Adjustment
Aviano 30 CCT Angle Adjustment You can adjust the angle of the device with the adjustment screws (01). 01) Turn the adjustment screws (01) counterclockwise to release them. 02) Tilt the device to the desired angle (Fig. 14). 03) Turn the adjustment screws (01) clockwise to tighten them. Make sure that the device cannot move freely. -
Page 16: Connecting To Power Supply
Aviano 30 CCT Connecting to Power Supply DANGER Electric shock caused by short-circuit The device accepts AC mains power at 220–240 V and 50/60 Hz. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. Make sure that the device is always electrically connected to the ground (earth). -
Page 17: Preventive Maintenance
Aviano 30 CCT Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ●... -
Page 18: Instructions For Transportation
Aviano 30 CCT Instructions for Transportation ● Use the original packaging to transport the device, if possible. ● Always observe the handling instructions printed on the outer carton box, for example: “Handle with care”, “This side up”, “Fragile”. Storage ●... - Page 19 Aviano 30 CCT Product code: A0720117...
- Page 20 ©2022 Artecta...
