- Page 1 USER MANUAL ENGLISH Argos LED Panel UGR <19 30x120 40W Product code: A0160210 – 3000K A0160211 – 4000K Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Argos LED Panel <19 30x120 40W Preface Thank you for purchasing this Artecta product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Argos LED Panel <19 30x120 40W Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 LEDs Lifespan ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................5 Safety .................................. -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Artecta Argos LED Panel UGR <19 30x120 40W + Driver ● User manual Fig. 01 Intended Use This device is intended for professional use as an architectural light spot. -
Page 5: Symbols And Signal Words
Argos LED Panel <19 30x120 40W Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 6: Symbols On The Information Label
Argos LED Panel <19 30x120 40W Symbols on the Information Label This product is provided with 2 information labels. The first information label is located on the back side of the device. The second information label is located on the topside of the driver. The information label contains the following symbols: This device is designed for indoor use. -
Page 7: Safety
Argos LED Panel <19 30x120 40W Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children... -
Page 8: Requirements For The User
Argos LED Panel <19 30x120 40W Attention Before use, examine the device visually for any defects. Make sure that: ● There are no deformations on housings, fixations and installation points. ● The lens is not cracked or damaged. ● The interconnecting power cable is not damaged and does not show any material fatigue. Attention Do not expose the device to conditions that exceed the rated IP class conditions. -
Page 9: Description Of The Device
Argos LED Panel <19 30x120 40W Description of the Device The Argos LED panels with UGR<19 are of high quality and are particularly suitable for office work and public spaces. You can think of rooms with computers, schools, hospitals and dental practices. A big advantage is that the front plate works as a diffuser. -
Page 10: Product Specifications
Argos LED Panel <19 30x120 40W Product Specifications Model: Argos LED Panel <19 30x120 40W Electrical: Input voltage: 220-240 V AC, 50/60 Hz Power consumption: 40 W PFC: 0,98 Physical: Dimensions: 1195 x 195 x 35 mm (L x W x H) Weight: 1,92 kg Mounting Depth... -
Page 11: Dimensions
Argos LED Panel <19 30x120 40W Dimensions Fig. 03 Fig. 04 Product code: A0160210 / A0160211... -
Page 12: Installation And Deinstallation
Argos LED Panel <19 30x120 40W Installation and Deinstallation Safety Instructions WARNING Incorrect installation and deinstallation can cause serious injuries and damage of property. Installation and deinstallation of the device must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning electrical installations in buildings and working at heights. -
Page 13: Mounting
Argos LED Panel <19 30x120 40W Mounting The device can be mounted only in a mounting frame or a common grid ceiling-system. CAUTION Restrict the access under the work area during mounting. To mount the device, please look at the manual of the following items: ●... -
Page 14: Operation
Argos LED Panel <19 30x120 40W Operation Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for. This device is intended for professional use as an architectural light spot. It is suitable for indoor installation in offices and public spaces. -
Page 15: Maintenance
Argos LED Panel <19 30x120 40W Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before use, examine the device visually for any defects. Make sure that: ●... -
Page 16: Transportation And Storage
Argos LED Panel <19 30x120 40W Transportation and Storage Instructions for Transportation ● Use the original packaging to transport the device, if possible. ● Always observe the handling instructions printed on the outer carton box, for example: “Handle with care”, “This side up”, “Fragile”. Storage ●... - Page 17 Argos LED Panel <19 30x120 40W Product code: A0160210 / A0160211...
- Page 18 Argos LED Panel <19 30x120 40W Product code: A0160210 / A0160211...
- Page 19 Argos LED Panel <19 30x120 40W Product code: A0160210 / A0160211...
- Page 20 ©2022 Artecta...
