HARBOR BREEZE and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at partsplus@lowes.com.
AS23111
ADARA FANDELIER
1
ITEM #5257160
MODEL #42958
Español p. 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the HARBOR BREEZE 42958 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LF HARBOR BREEZE 42958

Summary of Contents for LF HARBOR BREEZE 42958

  • Page 1 MODEL #42958 Español p. 15 HARBOR BREEZE and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-251-1003, 8 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents..............3 Preparation .

  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Mounting Bracket (preassembled to Canopy [C]) Canopy Screw (preassembled to Mounting Bracket [A]) Canopy Canopy Cover Downrod Motor Assembly Downrod Clip (preassembled to Motor Assembly [F]) Downrod Pin (preassembled to Motor Assembly [F]) Set Screw (preassembled to Motor Assembly [F]) Remote Pack Bulb PREPARATION...

  • Page 4: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. Failure to do so could lead to electrical shock, fire or other injuries that could be hazardous or even fatal. • Before you begin installing the fixture, disconnect the power by removing fuses or turning off the circuit breakers.
  • Page 5 SAFETY INFORMATION CAUTION: • This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1) This device may cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. •...

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 1. Turn off the circuit breakers and the wall switch to the supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. Loosen but do not remove the two canopy screws (B) at the bottom of the mounting bracket (A).
  • Page 7 ASSEMBLY INSTRUCTIONS 4. Remove the downrod clip (G) and downrod pin (H) from the yoke at the top of the motor assembly (F) and save for downrod (E) assembly. Then, loosen but do not remove the two set screws (I) at the top of the yoke.
  • Page 8 ASSEMBLY INSTRUCTIONS 7. Install the ball end of the downrod (E) into the opening of the mounting bracket (A). Rotate the downrod (E) until the tab in the mounting bracket (A) is seated in Slot the slot in the downrod ball. WARNING: The fan and/or downrod (E) should not rotate in the mounting bracket (A), if installed correctly.
  • Page 9 ASSEMBLY INSTRUCTIONS 10. Turn the spliced/taped wires upward and gently push the wires and wire connectors into the outlet box. WARNING: Ensure no bare wire strands are visible after making connections. Place the ground and neutral supply wire connections on opposite sides of outlet box from the hot wire connection.
  • Page 10 ASSEMBLY INSTRUCTIONS 13. Install the E26-base LED bulbs (K) into the sockets of the light kit. Important: Make sure you allow the bulbs and light kit to cool before you replace the bulbs. 14. Remove the battery cover from the back of the remote found in remote pack (J).

  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS 1. To operate the fan using the remote, press and release the following buttons: 1 - High fan speed 2 - Medium fan speed 3 - Low fan speed 4 - Fan Power - Turns the fan off. Light Delay Off mode - Press and hold the fan power button (4) for five seconds, which will turn off light after one minute.

  • Page 12: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year, tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Bulb Replacement: Use 40-watt max. E26-base LED, CFL or incandescent bulbs. Halogen bulbs are not recommended for this item.

  • Page 13: Warranty

    LIMITED LIFETIME WARRANTY Set forth below, the manufacturer warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also, subject to the limitations below, the manufacturer warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year after the date of purchase by the original purchaser at retail.
  • Page 14 REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at partsplus@lowes.com. PART DESCRIPTION PART# Mounting Bracket 4L000016910 Canopy 4L000016920 Canopy Cover 4L000016930 Downrod 4L000016940 Remote Pack...
