Summary of Contents for eta AQUILO PRO 7243
- Page 1 Роботи-пилососи ETA Aquilo PRO 7243 90000: Інструкція Обрати користувача...
- Page 2 10. EKOLÓGIA Ak to rozmery umožňujú, na všetkých dieloch sú vytlačené znaky materiálov, ktoré sú použité na obalový materiál, komponenty a príslušenstvo, ako aj na ich recyklovanie. Uvedené symboly na výrobku alebo v sprievodnej dokumentácii znamenajú, že použité elektrické alebo elektronické výrobky nesmú byť likvidované spoločne s komunálnym odpadom.
-
Page 3: General Safety Instructions
EN – Robot vacuum cleaner 4 in 1 with smart application AQUILO PRO 7243 INSTRUCTIONS FOR USE Dear customer, thank you for purchasing our product. Keep this instruction for use and cash receipt (if possible, including the package and its interior) for further reference. 1. - Page 4 • Don´t put hands close to rotating part. • Never immerse the vacuum cleaner into water (even its parts)! • Never vacuum without a properly inserted filtration system and micro-filters. • Do not vacuum sharp objects (e.g. glass, shatter), hot, flammable, explosive items (e.g.
- Page 5 Wireless connection and compatibility • The ETA company cannot be liable in any way for any incidental, indirect or consequential damages, or for any loss of data or loss due to information leakage during wireless communication.
- Page 6 Remove all easily damaged objects (including luminous objects, fabrics, Don’t stand or sit on the Cleaner, glass bottles, etc.) before using, or it may cause damage to the or it may cause damage to these Cleaner or personal injury. objects or affect the using of the cleaner.
-
Page 7: Product Components
3. PRODUCT COMPONENTS 3.1 PACKAGE CONTENTS AND OPTIONAL ACCESSORIES Item Description Designation Quantity Match code Robotic vacuum cleaner Dirt container ETA724300240 (installed in the device) Base Clean water tank (installed in the parking ETA724300200 station) Dirty water tank (installed in the parking ETA724300010 station) Dust bag... - Page 8 Item Description Designation Quantity Match code Cleaning tool ETA724300460 Cleaning brush ETA724300470 Battery ETA724300210 (installed in the device) 3.2 ROBOTIC VACUUM CLEANER A – Robotic vacuum cleaner C – Control panel A1 – Front bumper A2 – Sensors against falling downstairs H –...
-
Page 9: Control Panel
3.3 DUSTBIN B – Dirt container B1 – Dirt tank release button B2 – Dirt tank B3 – HEPA filter 3.4 CONTROL PANEL C – Control panel C1 – ON /OFF/AUTO (automatic cleaning) / STOP (PAUSE) button C2 – CHARGING / STOP (PAUSE) button 3.5 BASE EN - 50... -
Page 10: Preparation For Use
F – Dirty water tank D – Base D1 – Light indicator F1 – Lid D2 – Cleaning grate F2 – Tilting handle D3 – Charging contacts D4 – Access surface for the robot vacuum G – Dust bag D5 – Orifice for suction of dirt from the dirt container B D6 –... -
Page 11: Base Installation
4.2 BASE INSTALLATION 1. Place the base on the floor. Make sure there is enough space on the sides of the base (at least 0.5 m) and in front of the base (at least 1.5). Don´t expose the charging dock to sunshine. 2. -
Page 12: Switching On The Vacuum Cleaner
• Standard charging time is approx. 4-5 hours. Fully charged battery will work for approx. 180 minutes, depending on set functions. • The stated operating times are based on ETA‘s internal testing and only apply to a new and fully charged battery. Depending on the age and wear of the battery, the operating time decreases. - Page 13 Note If the robot vacuum is in the base connected to electric mains, it will never be switched to sleep mode and automatically switched off. 5.4 CLEANING MODES AND DEVICE FUNCTIONS WITHOUT USING THE ETA AQUILO APPLICATION Smart automatic cleaning Press button C1.
- Page 14 5.5 ROBOT VACUUM LIGHT INDICATORS Note Some light signals can have several meanings. Meanings of light signals are supported by voice notifications or, as the case may be, by relevant notifications in the "ETA AQUILO" application . Light indicator Information Cleaning...
- Page 15 In Easy Operation mode, the robot vacuum can be controlled using the buttons on control panel C. In order to use all device´s functions, you will have to install and use smart app "ETA AQUILO", allowing extension of vacuum cleaner functionality and increased user comfort.
- Page 16 2. Clean the dirt tank with the tool I (or other suitable). 3. Remove HEPA filter B3 from the dirt container and blow away/ knock out the filter carefully. You can also use cleaning instrument I. NOTICE • Do not use any aggressive washing or cleaning agents or hot water for cleaning HEPA filter. •...
-
Page 17: Main Brush Cleaning
7.3 MAIN BRUSH CLEANING 1. Press relevant locking elements, remove cover A8 and main brush A7. 2. Clean the main brush with the cleaning tool I (or other suitable). You can also use scissors to remove tangled hair / hair. Wipe the main brush cover and main brush compartment with a soft, dry cloth. - Page 18 NOTICE Some hair / pet’s hair may be wrapped around the wheel axes and other dirt may stick. Inspect and clean the wheels regularly. 7.6 SENSORS CLEANING When cleaning has been finished, wipe the sensors with soft damp cloth. 7.7 CLEANING ROTATION CLIPS FOR MOPS AND THE MOPS Remove rotation clips H from the robot vacuum and remove mops H1.
- Page 19 1. Disconnect base D from power mains before cleaning. Wipe base surface with soft damp cloth. Open lid D7 and remove dust bag G. Dispose the bag in ordinary waste. Install the bag back in place. 2. Remove clean water container E. Pour out remaining water. Remove suction hose E3 and clean foam filter E4.
-
Page 20: Problems Solutions
8. PROBLEMS SOLUTIONS Problem Solution Low battery. Place the robot vacuum on the base and charge the battery. The device cannot be switched on. Ambient temperature lower than 0 °C or higher than 35 °C. Working temperature of the device is 0-35 °C. Remove robot vacuum from the base and check its correct connection to electric mains. -
Page 21: Environmental Protection
220-240 V (AC) Declared acoustic level is 78 dB(A) re 1pW. Hereby, ETA a.s. declares that the radio equipment type ETA7243 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the ETA internet address. - Page 22 Battery removing Remove main brush cover A8. Remove the 4 battery compartment cover screws at the bottom of the vacuum cleaner. Remove the battery and unplug the connector. Remove the battery and unplug the connector. For unplugging the connector use more force for advantage of overcoming the safety fuse against spontaneous disconnection.
