Taurus Seated Row IFP Assembly And Operating Instructions Manual page 25

Front Frame ASSY (4)
Grade No. Part No.
4.1 IFP13020400
4.2 KPSFID3000
4.3 CG600010300
Left Arm Frame ASSY (5)
Grade No. Part No.
5.1 IFP13020500
5.2 FE97203100
5.3 KPSFID3000
5.4 V39500
5.5 V39600
5.6 GB2766205-2ZC3
5.7 GB77M8*6DHS2
5.8 YZGB7710-32*3.2N19
Right Arm Frame ASSY (6)
Grade No. Part No.
6.1 IFP13020600
6.2 FE97203100
6.3 KPSFID3000
6.4 V39500
6.5 V39600
6.6 GB2766205-2ZC3
6.7 GB77M8*6DHS2
6.8 YZGB7710-32*3.2N19
Description
Front Frame
Plug 50.8
Ø
Rubber Bumper
Description
Left Arm Frame
Grip STΦ31*Φ24*308
Plug 50.8
Ø
Aluminum Grip Ring
Aluminum Grip Cap
Deep Groove Ba l BearingΦ25*Φ52*15
Socket Set Screw M8*6
Socket Set Screw 10-32UNF*3.2
Description
Right Arm Frame
Grip STΦ31*Φ24*308
Plug 50.8
Ø
Aluminum Grip Ring
Aluminum Grip Cap
Deep Groove Ba l BearingΦ25*Φ52*15
Socket Set Screw M8*6
Socket Set Screw 10-32UNF*3.2
Qty.
1
2
2
Qty.
1
1
1
1
1
2
1
4
Qty.
1
1
1
1
1
2
1
4
25
