Arkon TAB4XLMETKL Quick Start Manual

TAB4XLMETKL | Extra Large Universal Aluminum Locking Tablet Mount with 4-Hole Metal AMPS Base
TAB4XLKL-B
Mounting Base & Holder
1
Using a screwdriver and/or drill, attach the metal AMPS mounting base to a
flat surface with 4 screws (not included).
Inserting Tablet
3
Locking Arm Locking Arm
To size the tablet holder to your tablet, begin by unlocking the top of the
tablet holder with the key and push up on the locking arm.
5
Unscrew the screws at the bottom sides of the holder to adjust the tablet
holder's width to the tablet. Tighten to secure.
Safety Precautions
!
Arkon is not responsible for any damages caused to your device or yourself
due to the installation or use of this mount.
SP-12M-4M7
RM38352XMAMPSSH RM38352XMAMPSSH
SPRMLGKNOBNL
Package Contents:
(1) TAB4XLKL-B – Extra Large Universal Locking Adjustable Aluminum Tablet Holder
with Key Lock and Keys
(1) RM38352XMAMPSSH – 5.5" Metal 4-Hole AMPS Mount – 38mm (1.5 inch)
Ball Compatible
(1) SP-12M-4M7 – Screw Pack
Optional (for converting locking tablet holder to NON-LOCKING option):
(1) SPRMLGKNOBNL – Large Robust Shaft Knob (see page 2)
Device Compatibility: Fits 10"-12" screen size tablets
Tools Needed: 7mm and 10mm socket wrenches
2
Connect the tablet holder to the mounting base (screws provided) using
the 4-Hole AMPS mounting pattern. Loosen adjustment knob to reposition
shaft, retighten to desired position.
4
Unscrew the three screws/washers at the back/center of the holder to adjust
the tablet holder's height to the tablet (not included). Retighten the screws/
washers to secure.
6
To lock down tablet, close down on the locking arm on the top of the tablet
and lock with key (included).
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
rev.070821
(Tablet not included)
Adjust
Unscrew
to adjust
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in Taiwan
© Copyright 2021 Arkon Resources, Inc.
