- Page 1 INSTALLATION INSTRUCTIONS VOLT SOLAR LANDSCAPE LIGHTING ® VOLT Solar Modernelle Integrated LED Path & Area Light ® ITEM: VSPL-1054-BBZ 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS VOLT Solar Modernelle- VSPL-1054-BBZ ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. -
Page 3: Package Contents
PACKAGE CONTENTS A. (1) Fixture Body B. (2) Batteries PARTS REQUIRED (SOLD SEPARATELY) A. (1) Mounting Accessory PRODUCT DIMENSIONS 6.67” 1.97” 5.53” 22” 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com... -
Page 4: Remove Battery Cover
INSTALLATION INSTRUCTIONS VOLT Solar Modernelle- VSPL-1054-BBZ ® REMOVE SOLAR COMPONENTS FROM FIXTURE BODY Fixture Body Remove the screws Screw to separate the solar components from the fixture body. Solar Components REMOVE BATTERY COVER Remove the battery cover. Solar Components Screw... -
Page 5: Install Batteries
INSTALL BATTERIES Insert two batteries into the battery compartment. Solar Components Battery Battery Compartment INSTALL BATTERY COVER Place the battery cover back onto the battery compartment and secure with previously Solar Components removed screws. Screw Battery Cover Battery Compartment 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com... - Page 6 INSTALLATION INSTRUCTIONS VOLT Solar Modernelle- VSPL-1054-BBZ ® INSTALL SOLAR COMPONENTS BACK INTO FIXTURE BODY Fixture Body Place the solar components Screw back into the fixture body and secure with previously removed screws. Solar Components TEST SOLAR LIGHT Cover solar panels completely Black Material by using black materials.
- Page 7 INSTALL STAKE TO FIXTURE BODY Thread the stake onto the bottom of the fixture body. Fixture Body Stake INSTALL STAKE INTO SOIL Insert the stake into the soil until flange of stake is flush to the ground. Fixture Body Ground Stake Soil 813.978.3700 •...
- Page 8 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
