INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
®
VSSI-2005-50-BK
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2021, VOLT
customersupport@voltlighting.com • 813.978.3700
Solar Landscape Lighting
Solar Bistro String Lights (50ft)
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSSI-2005-50-BK and is the answer not in the manual?

Questions and answers

Related Manuals for Volt VSSI-2005-50-BK

Summary of Contents for Volt VSSI-2005-50-BK

  • Page 1 VSSI-2005-50-BK Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...

  • Page 2: Important Safety Instructions

    INSTALLATION INSTRUCTIONS VOLT Solar Bistro String Lights (50ft) ® VSSI-2005-50-BK Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.

  • Page 3: Package Contents

    Package Contents A. (1) Solar Panel E. (32) Bulbs (2 replacement bulbs are included) B. (1) Support Arm F. (1) Stake C. (1) Clamp with Support Arm G. (4) Straps D. (1) Bistro String (50 feet long) H. (4) Screws I.
  • Page 4 INSTALLATION INSTRUCTIONS VOLT Solar Bistro String Lights (50ft) ® VSSI-2005-50-BK Follow 1 of the 4 Solar Panel Mounting Methods Method 1: Clamp Mount Mount Clamp with Support Arm Support Arm Clamp Clamp Mounting Surface Mounting Surface Attach the clamp onto the side of the mounting surface.

  • Page 5: Surface Mount

    Method 2: Surface Mount Surface Mount Mark Place the support arm onto the surface and mark points using Wall Anchor the holes as a guide. Then, drill Screw proper holes for the wall anchors to be inserted. Attach the support arm onto the surface using the screws.
  • Page 6 INSTALLATION INSTRUCTIONS VOLT Solar Bistro String Lights (50ft) ® VSSI-2005-50-BK Method 3: Straps Mount Insert Straps Strap Pass the ends of the strap through two holes on the support arm. Support Arm Tie the Strap Install the support arm by...
  • Page 7 Method 4: Stake Mount Install Stake to Support Arm Insert the top end of the stake into the base of support arm. Support Arm Stake Insert Stake to Ground Insert the stake into the ground. Then go to the Installing Solar Support Arm Panel and Bistro String steps.
  • Page 8 INSTALLATION INSTRUCTIONS VOLT Solar Bistro String Lights (50ft) ® VSSI-2005-50-BK Install Solar Panel and Bistro String Remove Wire Cover Twist and remove the wire cover from the solar panel. Solar Panel Wire Wire Cover Connect Wires Connect the wire from bistro string to the wire from the solar panel.
  • Page 9 Test Solar Panel Place the solar panel onto a flat FLAT SURFACE opaque working surface. Press the ON/OFF switch on the back of the solar panel to test the light source. The light will turn on BACK while the switch is on. Now you can proceed to next steps of installations knowing the fixture is in ON mode.

  • Page 10: Final Adjustment

    INSTALLATION INSTRUCTIONS VOLT Solar Bistro String Lights (50ft) ® VSSI-2005-50-BK Install Remaining Bulbs Thread bulbs onto the sockets and tighten gently. Socket Bulb Final Adjustment Loosen the screw at the knuckle ROTATE to adjust the solar panel to make sure it can get plenty of sunlight.

  • Page 11: How To Replace Battery

    How to Replace Battery 1. Using a screwdriver, remove Screw the screws from the cover on Cover the back of the solar panel. 2. Remove the cover. Battery 3. Remove the battery out of Solar Panel the battery compartment and replace it with a new one.
  • Page 12 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
