- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT Max Spread Stainless Steel Path & Area Light ® ITEM: VSM-2407/1203 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT Max Spread Stainless Steel Path & Area Light - VSM-2407/1203 ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Stem Parts Required (sold separately) A. (1) Hat C. Stake B. (1) Bulb Product Dimensions Max Spread Hat Pictured Here Max Spread Hat Pictured Here on on Mini stem Standard stem 9” 2.5” 22.5” 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Max Spread Stainless Steel Path & Area Light - VSM-2407/1203 ® Remove Stem Top Loosen the stem top and remove it from the stem. Stem Top Stem Install Bulb Insert the bulb with correct Bulb wattage and type marked on the...
- Page 5 Install Stake Determine the desired location Board for mounting the fixture. Ham- mer the stake into the ground until the flange of the stake is flush to grade. To avoid damage Stake to the stake, place a board on top of the stake while hammer- Ground ing.
- Page 6 Wire Connection Pigtail Wire Connectors Main Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold separately), connect the leads from the luminaire to the main supply cable leads. Install Spun Brass Hat to Stem (Option A) Place the hat of your choice Finial onto the stem top and se-...
- Page 7 Install Cast Brass Hat to Stem (Option B) Thread the hat of your choice Hat of onto the stem top. Hand your tighten until snug. choice Note: For Cast Brass hats you will not need a finial to Stem install the hat. You will screw the hat directly to the top of the stem using the coupler.
- Page 8 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
