Ledra Brands THETA 750 SNAP Operating Instructions Manual

CONTENTS
GENERAL NOTES .................................................... 1
EQUIPMENT CHECKLIST ........................................ 2
THETA 750 SNAP DRILL JIG CASE CONTENTS .... 3
THETA 750 SNAP DRILL JIG PARTS ....................... 4
HOW THE DRILL JIG WORKS ................................. 5
1. MARK THE LED POSITIONS ............................... 6
2. INSPECT THE CUTTER ASSEMBLY ................... 7
3. INSTALL / REPLACE THE CUTTERS .................. 8
4. SET THE DRILL ANGLE ....................................... 9
5. LUBRICATE THE CUTTERS .............................. 10
6. CLAMP DRILL JIG TO RAIL .................................11
7. CHECK YOUR DRILL SETUP ............................. 12
8. DRILL THE HOLE................................................ 13
9. REMOVE DRILL JIG AND CLEAN ...................... 14
TROUBLESHOOTING GUIDE ................................ 15
DRILL JIG FLAT FACE SET UP .............................. 15
v.2.14.24
THETA750 SNAP Drill JIG Instruction Sheet
Operating Instructions
THETA 750 SNAP - DRILL JIG MANUAL
READ BEFORE USE
The following instructions are designed to help you operate the THETA 750 SNAP DRILLING JIG in a
safe, efficient and professional way. To ensure continual improvement, we welcome your feedback on this
manual sent to info@ledrabrands.com

GENERAL NOTES

- The THETA 750 SNAP DRILL JIG is designed to be used with a battery-operated (cordless) drill ONLY
set to SLOW speed.
- The THETA 750 SNAP DRILL JIG is intended for use installing the latest generation LED Puck Snap-type
modules ONLY.
This includes Snap, Solo, Zero, RGBW, Wide and IP68 modules. DO NOT USE for threaded (screw-in)
LED Puck installations.
- NOTE! Square pipe / flat-faced rail applications require a spacer installed in the Drill Jig.
Refer to the supplementary guide: Drill Jig Flat Face Setup.
- If the Drill Jig is not functioning as expected please contact LedraBrands ASAP at (714) 259-9959
- DO NOT USE IMPACT OR HAMMER DRILL
Read all safety warnings and
instructions. Failure to follow
instructions may result in injury.
Led puck hole preparation and drilling
should be carried out by skilled
personnel only.
The drill jig must be used with a
battery-operated (cordless) drill
only set to slow speed.
Do not use a rotary/impact/hammer
drill or such settings on your chosen
drill. Drill must be set to 'drill/driver'
setting and slow/low speed.
In a continuing effort to offer the best product possible we reserve the right to change, without notice, specifications or materials that in our opinion will not alter the function of the product.
A maximum 400rpm drill is
recommended. Do not use a higher rpm
drill as it will shorten the life of the cutter
and cause work hardening of the rail.
Read and observe the safety precautions
and operating instructions on your
chosen drill and equipment.
The drill jig contains sharp and
fast moving parts that can cause
harm if used incorrectly.
Do not clean with compressed air. This
may cause shavings to be wedged
between components causing issues.
Ledra Brands Inc. 88 Maxwell
www.LedraBrands.com Irvine, CA 92618
Always use ear plugs or ear muffs when
drilling to avoid hearing damage.
Drilled metal and (shavings)
can be hot enough to burn and
injure. Use appropriate personal
protective equipment (PPE) such as
goggles, gloves and safety boots.
The drill jig has been designed for
use with the supplied 15mm and
16mm cutters only. Do not use
other cutters unless instructed.
Remove or replace cutters only as shown
in this manual. Please notify your supplier
if the cutters do not perform as described.
Do not attempt to modify the drill jig or
operate it outside of the range described
within this manual. Modifications
or tampering with the drill jig may
result in deposit not refunded.
F 714.259.9969
P 714.259.9959
1
