Operating Instructions
ZETA 750 SNAP - DRILL JIG MANUAL
READ ALL SAFETY WARNINGS AND
INSTRUCTIONS. FAILURE TO FOLLOW
INSTRUCTIONS MAY RESULT IN
PERSONAL INJURY.
LED PUCK HOLE PREPARATION AND
DRILLING SHOULD BE CARRIED OUT
BY SKILLED PERSONNEL ONLY.
THE DRILL JIG MUST BE USED WITH A
BATTERY-OPERATED (CORDLESS) DRILL
ONLY SET TO SLOW SPEED.
DO NOT USE A ROTARY/IMPACT/HAMMER
DRILL OR SUCH SETTINGS ON YOUR
CHOSEN DRILL. DRILL MUST BE SET TO
'DRILL/DRIVER' SETTING AND SLOW/LOW
SPEED.
v.8.29.19
READ BEFORE USE
The following instructions are designed to help you operate the Drill Jig in a safe, efficient and professional way.
To ensure continual improvement, we welcome your feedback on this manual sent to info@ledrabrands.com
CONTENTS
This document contains 8 parts:
1. General Notes / Cautions (this page)
2. Equipment Checklist
3. Drill Jig Case Contents
4. Drill Jig Parts
5. How The Drill Jig Works
6. Instructions For Use
7. Troubleshooting Guide
8. Supplementary Guide: Drill Jig Flat Face spacer Setup
A MAXIMUM 400RPM DRILL IS RECOMMENDED.
DO NOT USE A HIGHER RPM DRILL AS IT WILL
SHORTEN THE LIFE OF THE CUTTER AND
CAUSE WORK HARDENING OF THE RAIL.
READ AND OBSERVE THE SAFETY PRECAUTIONS
AND OPERATING INSTRUCTIONS ON YOUR CHOSEN
DRILL AND EQUIPMENT.
THE DRILL JIG CONTAINS SHARP AND FAST
MOVING PARTS THAT CAN CAUSE HARM IF
USED INCORRECTLY.
DO NOT CLEAN WITH COMPRESSED AIR.
THIS MAY CAUSE SHAVINGS TO BE WEDGED
BETWEEN COMPONENTS CAUSING ISSUES.
In a continuing effort to offer the best product possible we reserve the right to change, without notice, specifications or materials that in our opinion will not alter the function of the product.
GENERAL NOTES
- The Drill Jig is designed to be used with a battery-operated (cordless) drill ONLY set to SLOW speed.
- The Drill Jig is intended for use installing the latest generation LED Puck Snap-type modules ONLY. This includes
Snap, Solo, Zero, RGBW, Wide and IP68 modules. DO NOT USE for threaded (screw-in) LED Puck installations.
- NOTE! Square pipe / flat-faced rail applications require a spacer installed in the Drill Jig. Refer to the supplementary
guide: Drill Jig Flat Face Setup.
- If the Drill Jig is not functioning as expected please contact LedraBrands ASAP at (714) 259-9959
CAUTIONS
Ledra Brands Inc.
www.LedraBrands.com
ALWAYS USE EAR PLUGS OR EAR MUFFS WHEN
DRILLING TO AVOID HEARING DAMAGE.
DRILLED METAL AND SWARF (SHAVINGS) CAN BE
HOT ENOUGH TO BURN AND INJURE. USE APPROPRIATE
PERSONAL PROTECTIVE EQUIPMENT (PPE) SUCH AS
GOGGLES, GLOVES AND SAFETY BOOTS.
THE DRILL JIG HAS BEEN DESIGNED FOR USE
WITH THE SUPPLIED 15MM AND 16MM CUTTERS
ONLY. DO NOT USE OTHER CUTTERS UNLESS
INSTRUCTED.
REMOVE OR REPLACE CUTTERS ONLY AS SHOWN
IN THIS MANUAL. PLEASE NOTIFY YOUR SUPPLIER
IF THE CUTTERS DO NOT PERFORM AS DESCRIBED.
DO NOT ATTEMPT TO MODIFY THE DRILL JIG OR
OPERATE IT OUTSIDE OF THE RANGE DESCRIBED
WITHIN THIS MANUAL. MODIFICATIONS OR
TAMPERING WITH THE DRILL JIG MAY RESULT
IN DEPOSIT NOT REFUNDED.
15774 Gateway Circle Tustin, CA 92780
P 714.259.9959 F 714.259.9969
