- Page 1 70" MONARCH Product images may vary slightly from actual product. INSTRUCTION MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INSTALLING THE SWITCH HOUSING......15 SAFETY RULES................4 INSTALLING THE BATTERIES..........TOOLS REQUIRED..............OPERATING INSTRUCTIONS..........PACKAGE CONTENTS............. INSTALLING THE WALL CONTROL MOUNTING OPTIONS............. SYSTEM WALL PLATE............HANGING THE FAN..............OPERATION INSTRUCTIONS..........INSTALLATION OF SAFETY SUPPORT......TROUBLESHOOTING............. ELECTRICAL CONNECTIONS..........FINISHING THE INSTALLATION........ -
Page 4: Safety Rules
SAFETY RULES 1. To reduce the risk of electric shock, insure electricity has been 8. Avoid placing objects in the path of the blades. turned off at the circuit breaker or fuse box before beginning. 9. To avoid personal injury or damage to the fan and other items, be cautious when working around or cleaning the fan. -
Page 5: Tools Required
TOOLS REQUIRED PACKAGE CONTENTS Philips screw driver Unpack your fan and check the Blade screw driver contents. You should have the 11 mm wrench following items: Step ladder Wire cutters a. Fan blades (5) b. Canopy & Ceiling mounting bracket c. -
Page 6: Mounting Options
MOUNTING OPTIONS If there isn't an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials. -
Page 7: Hanging The Fan
HANGING THE FAN Hanger bracket REMEMBER to turn off the power before you begin. To properly install your ceiling fan, follow the steps below. Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy cover Step 2. - Page 8 HANGING THE FAN (continued) Supply wires Step 6. Loosen the two set screws and remove the hitch pin and Downrod retaining clip from the coupling on top of the motor assembly. (Fig. Set screws Retaining clip Set screws Step 7. Carefully feed the electrical lead wires from the fan up Hitch pin through the downrod.
- Page 9 HANGING THE FAN (continued) Step 8. Slip the top motor cover, coupling cover, canopy cover and Downrod canopy onto the downrod. (Fig. 9) Canopy Secure the top motor cover to the motor by using the three top Canopy cover motor cover set screws provided, but do not tighten at this time. Thread the hanger ball onto the downrod, insert the cross pin Coupling cover through the downrod and tighten.
-
Page 10: Installation Of Safety Support
INSTALLATION OF SAFETY SUPPORT (required for Canadian installation ONLY) A safety support cable is provided to help prevent the ceiling fan from falling. Step 1. Attach the provided wood screw and washers to the ceiling Ceiling mounting joist next to the mounting bracket but do not tighten. (Fig. 11) Attach bracket safety cable... -
Page 11: Electrical Connections
ELECTRICAL CONNECTIONS Code switch WARNING: To avoid possible electrical shock, be sure you have turned off the power at the main circuit panel. ON ECE LIGHT 1 2 3 4 Follow the steps below to connect the fan to your household wiring. ON ECE FAN OFF Use the wire connecting nuts suppled with your fan. - Page 12 ELECTRICAL CONNECTIONS (continued) Outlet box Step 2. Motor to Receiver Electrical Connections: (Fig. 14) Connect the White (neutral) Black (hot) black wire from the fan to the black wire marked "TO MOTOR L" on Green or bare copper (ground) the receiver. Connect the white wire from the fan to the white wire Black ("AC IN L") marked "TO MOTOR N"...
-
Page 13: Finishing The Installation
FINISHING THE INSTALLATION Step 1. Tuck all the connections neatly into the ceiling outlet box. Outlet box Step 2. Slide the canopy up to the mounting bracket and place one of the key hole slots over the mounting screw on the mounting Ceiling bracket. -
Page 14: Attaching The Fan Blades
ATTACHING THE FAN BLADES Step 1. Attach a blade to a blade bracket using the screws, spring washers and fiber washers provided. (Fig. 16) Make sure the blade is straight when set on the blade bracket. Tighten each mounting screw and then repeat this procedure for each blade. -
Page 15: Installing The Switch Housing
INSTALLING THE SWITCH HOUSING NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Step 1. Loosen the 3 screws from the mounting plate. Step 2. Raise and hold the switch housing close to the mounting plate. -
Page 16: Installing The Batteries
INSTALLING THE BATTERIES Remove the face plate of the Wall Switch by lifting at the top and then insert the supplied 12V battery. Duracell MN21/Eveready A23/GP 23A all 12V. Replace the switch face plate. ON ECE 1 2 3 4 To prevent possible damage to the transmitter, remove these batteries if not used for long periods of time (months). -
Page 17: System Wall Plate
INSTALLING THE BASIC FUNCTION Outlet box Switch WALL CONTROL SYSTEM WALL Wall plate PLATE Select a location to install the Basic Function Wall Control System Transmitter and Wall Plate. Install the wall plate using an existing wall switch outlet box. Make sure the electrical power is TURNED OFF at the main panel before continuing. -
Page 18: Operation Instructions
OPERATING INSTRUCTIONS NOTE: To change the airflow direction of your ceiling fan use the REV button on the wall control transmitter. NOTE: To operate the reverse function on this fan, press the reverse button while the fan is running. Warm weather - Forward (counter clockwise) A downward airflow creates a cooling effect as shown in Fig. -
Page 19: Troubleshooting
TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. Fan sounds noisy. 1. Make sure all motor housing screws are snug. 2. - Page 20 www.kichler.com KICHLER® LIGHTING 7711 EAST PLEASANT VALLEY ROAD P.O. BOX 318010 CLEVELAND, OHIO 44131-8010 CUSTOMER SERVICE 866.558.5706 8:30 AM TO 5:00 PM EST, MONDAY - FRIDAY...
