Magnescale uMATE+ LU20 Instruction Manual

Digital Indicator
LU20 (F)
Safety Precautions
Magnescale Co., Ltd. products are designed in full consideration of
safety. However, improper handling during operation or installation
is dangerous and may lead to re, electric shock or other accidents
resulting in serious injury or death. In addition, these actions may also
worsen machine performance.
erefore, be sure to observe the following safety precautions in order to
prevent these types of accidents, and to read these "Safety Precautions"
before operating, installing, maintaining, inspecting, repairing or
otherwise working on this unit.
Warning Failing to follow the precaution items given
below may lead to severe injury or death.
• Be sure to use our dedicated batteries supplied with the
product or our dedicated accessory DZ60 (sold separately)
In no event will Magnescale Co., Ltd. be liable to you for
any accident or malfunction arising out of use of batteries
RISK OF FIRE
other than the dedicated batteries.
• When charging the batteries, do not remove them from
the LU20. Be sure to charge the batteries via the LU20
main unit.
FORCE
• Be careful not to mistake the plus and minus when
replacing the batteries.
• Do not drop or apply strong shocks to the product.
could result in a malfunction or battery trouble.
• Discontinue use of the product if there is any abnormality
such as deformation, abnormal appearance, unusual
odor, or heat generation.
• Avoid storage in the status with the batteries fully
charged or completely discharged. When storing for a
long time, charge the unit once every 2 or 3 months to
avoid accidents due to over-discharge.
• Avoid use in an atmosphere charged with in ammable
gases as this may result in re.
Failing to follow the precaution items given
Caution
below may lead to injury or damage to
surrounding objects.
• Provide adequate safety measures to prevent damages
in case our products should develop malfunctions.
•
e accessory mounting stand uses a powerful magnet.
Be careful as if electronic devices, magnetic recording
CAUTION
media, or magnetic cards etc. are brought close to
it, recorded contents may be destroyed or items may
become magnetized, making them unusable.
Precautions
• A USB charger is not included. A 10W or more commercially
available USB charger must be provided by the customer.
•
is product is a wireless device, so it can be used only in countries
where it is certi ed. Contact us if the product will be used outside
the country of purchase.
•
is product supports Bluetooth communication, but the Bluetooth
function is set to OFF by default. When not using the Bluetooth
function, leave it OFF.
• Check the frequencies used by surrounding devices before using
the Bluetooth function. Communication may be a ected if the
frequencies are the same.
is used by industry, science, medical devices, factories, etc., and
operated by private wireless stations and speci ed low-power
wireless stations.
•
e communication range with a connected Bluetooth device is
approximately 20 m in clear line-of-sight, but will become shorter if
there are obstacles or wireless interference.
•
is product is equipped with lithium-ion rechargeable batteries.
When transporting, be sure to observe the laws and regulations of
each country and the transport company's instructions.
•
is product is an industrial device and is not intended for general
consumers. e user is responsible for disposal of this product and
the batteries in accordance with laws and regulations.
For operation and battery replacement, refer to the
Instruction
LU20 Operating Manual available on our website.
Manual
e frequency band used by this product
www.magnescale.com Digital Gauge Products
•
e batteries are consumables and the service life will vary
according to the operating environment.
the fully charged status will gradually decrease with the number of
charging times and the passage of time since the start of use. Replace
the batteries when they become depleted due to prolonged use.
• Use under conditions or environments outside indicated
speci cations or purposes and modi cation of our products will
void any warranty of the functions and performance as speci ed of
our products.
• When using our products in combination with other equipment,
the functions and performance as noted in this manual may not
be attained, depending upon operating environmental conditions.
Make full study of the compatibility in advance.
Handling precautions
is
Noise sources
such as high-power
relays
•
e main unit, touch panel, mounting stand, USB charger, cables,
and rubber items may deteriorate due to oil or organic solvents. If
dirt adheres, moisten a so cloth with diluted neutral detergent, etc.
and wipe it o gently.
• A er unpacking, wipe the screen with a so , dry cloth and attach
the LCD protective sheet (accessory).
•
is product uses lithium-ion rechargeable batteries. Charge the
batteries before use.
Charging
Open the rubber cover on the top of the main unit and connect the
USB cable (accessory) to the main unit and to the USB charger. A er
charging, rmly close the rubber cover.
USB Type-C
connector
USB charger
Notes
Do not apply excessive force when connecting and disconnecting the connector.
• Charge by supplying power to the USB Type-C connector of the main unit. (USB
PD2.0)
• Power can also be supplied from a PC.
• e main unit also works while charging.
Do not expose to
coolant, oil, water, etc.
Coolant
Oil
Water
Separate by 0.5 m
or more
Attach with the protrusion at
the upper right.
Peel o the
backing sheet.
LCD protective sheet
USB cable
(accessory)
Rubber cover
e operating time from
Do not pull on the
cable
Do not disassemble
or modify
Close the rubber
cover after charging.
Charging indication
