2 Operation with Command Line

Overview

This section provides information on the following topics:
•
Getting started with the 130-SMHR-C and quick power up.
•
Minimum hardware configuration.
•
General operation with command line control.
•
DAS control with the command line.
•
Port settings and modem communications.
•
General GPS operations.
•
Example configuration with a command set
•
Format Media
•
Sample LED displays

Getting started with your 130-SMHR-C

This introductory material provides the following:
•
A brief procedure to establish minimal hardware connections for the recorder in order to
perform an initial system power-up.
•
External cables required.
•
Minimum hardware connection and power-up.
•
A procedure to specify an abbreviated set of operating parameters, start and verify data
acquisition, and save collected data to a file.
These instructions do not provide you with the detailed comprehensive information you need to
prepare your recorder for field deployment and 'real' data collection. The complete process to
establish all hardware connections, select and implement parameters, and perform data
acquisition is only outlined in this section for rapid familiarization.

Establishing Minimal Hardware Connections

These instructions cover the hardware and connections needed to perform the recorder
operations described in the rest of this section and lab setup.
To perform the system power-up, you need the following hardware:
•
A 130-SMHR-C.
•
A personal computer; either a laptop or desktop, with appropriate control interface like
SMCC, including a dumb terminal.
•
An external 12 volt power supply (you can use a 12 volt car battery).
