Mating Connectors; 130-Smhr-C Specifications - Reftek 130-SMHR-C User Manual

Rev J

Mating Connectors

Function
Serial
Power
GPS
NET
Channel
Modem
Relay

130-SMHR-C Specifications

Mechanical
Size
Weight
Watertight Integrity
Shock
Operating Temperature
Connectors
Power
NET
Serial
GPS
Channel (4-6)
Modem
Relay
Power
Input Voltage
Operating Power
Peak Power
Battery Charger
Battery
A/D Converter
Type
Channels
Input Impedance
Input Full Scale
Bit Weight
Self Noise Level
Sample Rates
Dynamic Range
Time Base
Type
Accuracy
Accuracy without GPS
Auxiliary Channels
Inputs
2
REF TEK 130-SMHR-C Users Guide
96480-00-UG
Mating Connector
PT06SE12-10S
PT06A12-4P
PT06SE12-8P
PT06SE14-19S
PT06SE14-19P
PT06A12-3S
PT06SE14-15S
Description
9.25" high x 8.0" long x 13.25"
(235mm x 203mm x 336mm)
10.5 lbs (4.8 kg) without internal battery
IP67
Survives 1 meter drop on any axis
-20° C to +60° C
Part Number
PT07A12-4S
PT07A14-19P
PT07A12-10P
PT07A12-8S
PT07A14-19S
PT07A12-3P
PT07A14-15P
10 to 16 VDC
2 W (3-channel @ 125sps)(without power for external sensors)
3 W (DAS and GPS active, writing to CF)
12 V, 800 mAmp
12 VDC, sealed lead-acid, 12 AmpH (optional, internal)
∆-∑ modulation, 24-bit resolution
3 or 6 channels
Matched to accelerometer
Matched to accelerometer
1.589 µV
2 counts RMS @ 200 sps
1000, 500, 250, 200, 125, 100, 50, 40, 25, 20, 10, 5, 1 sps (User selectable)
>137 dB
GPS Receiver/Clock plus a disciplined oscillator
± 10µsec with GPS locked and a validated 3-D fix
0.1 ppm from 0° to 60° C,
0.2 ppm from -20° to 0°
Battery, Temperature, and Backup Battery
