Mounting Adapters

Y92F-53 (Two included.)
This accessory is not included with the
product. Order it separately to mount
the product to a panel.
End Plate
PFP-M
Spacer
PFP-S
End Cover
Y92F-54 (Two included.)
96
34.7
12
11.8 9.4
10
6.2
1.8
M4×8
pan head
1
screw
50
35.5 35.3
1.8
11.5
10 1.3
M4 spring washer
4.8
16
5 12
34.8
44.3
16.5
3.9
5.3
68
Short Bars
Y92S-P11 (Four included.)
Use this product to connect between terminals (for power supplies,
communications, etc.) when you use multiple E5DC Controllers.
DIN Tracks
PFP-100N
PFP-50N
4.5
15 25 25
10
1000 (500) *
* Dimensions in parentheses are for the PFP-50N.

Unit Labels

Y92S-L2
The Unit Labels for the Digital Panel
Meter are used. Use either the °C or °F
label from the sheet.
Use the End Cover when you mount the E5DC/E5DC-B to a
panel to hide the gap between the Controller and the panel.
E5DC/E5DC-B
27.5
2.4
22.5
24.8
0.8
3
5
7.3
±0.15
35 27
±0.3
15 (5) *
25 25
1
10
±0.15
75
