Connectors

4.1
This chapter describes the implementation of the relevant connectors and headers on AFE Control Board-SAM4C
and their connection to the ATSAM4C.
4.1.1

I/O Extension Headers

The AFE Control Board-SAM4C has a dual row, 20 pin, 100mil extension male header (J8). J8 offers access to
the I/O of the microcontroller in order to expand the board, e.g. by connecting extensions to the board. Table 4-1
shows the pin assignment of J8. User can also expand the function by customized development.
Table 4-1 Pin Assignment of J8
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
4.1.2

Communication Connector

The AFE Control Board-SAM4C has a dual row, 20 pin, 100mil communication male connector (J7). When
connecting to the daughter board, the AFE Control Board-SAM4C can communicate with it through J7. Table 4-2
shows the definition of J7.
Table 4-2 Definition of J7
Pin Name
PB11
GND
NC
NC
NC
NC
PC6
PC7
PC8
PA23
PA24
PA25
PA11
PA12
PA22
PA7
PA6
PA8
GND
VCC
Description
SAM4C GPIO PB11
Ground
Null
Null
Null
Null
SAM4C GPIO PC6
SAM4C GPIO PC7
SAM4C GPIO PC8
SAM4C GPIO PA23
SAM4C GPIO PA24
SAM4C GPIO PA25
SAM4C GPIO PA11
SAM4C GPIO PA12
SAM4C GPIO PA22
SAM4C GPIO PA7
SAM4C GPIO PA6
SAM4C GPIO PA8
Ground
Power for extension board
AFE Control Board-SAM4C [User Guide] 7
