AFE Control Board-SAM4C

3.
The AFE Control Board-SAM4C supports Atmel Software Framework (ASF) drivers and demo code. The
software program is developed in environment such as IAR Embedded Workbench for ARM .

Debugger

3.1
SAM-ICE can program and debug the AFE Control Board-SAM4C. Customer can also use other instruments for
programming and debugging. A JTAG debug port is designed on the AFE Control Board-SAM4C.

Power Supply

3.2
The AFE Control Board - SAM4C can be powered either by external DC 9V power source or extended connector
J7. Detailed information is described in Table 3-1.
Table 3-1 Power Sources for the AFE Control Board-SAM4C
Power Input
External DC
Extension Port
The Control Board contains one backup battery. During the outage, the backup battery can provide power supply
so that the Real Time Clock (RTC) can keep working.

Standard Headers and Connectors

3.3
3.3.1

Power Header

The power header (PW1) can be used to connect external power to the AFE Control Board-SAM4C.
When JP6 is connected, the control board is powered by 3.3V. User can measure power consumption by
connecting to an ammeter serially.
When JP7 is connected, on-board 3.3V power route is connected to external power (EXT_VDD).
3.3.2

JTAG Debug Connector

The AFE Control Board-SAM4C has a dual row, 20 pin, and 100mil JTAG Debug header.
For detailed information of JTAG debug header, please refer to SAM-ICE.pdf.
Input Voltage Current Requirement
Requirement
9V
3.3V
JP6
3.3V
VDD
Figure 3-1 J1 Power Selection
500mA ~ 2A
100mA EXT_VDD( Pin20 of J7)
JP7
3.3V
EXT_VDD
AFE Control Board-SAM4C [User Guide]
Connector Name
PW1
