Cabling Recommendations; Supported Fiber Optic Cables - RuggedCom SIMATIC NET RS416PF Equipment Manual

For more information, refer to
view/109479891.
Note the different national regulations.
1.5

Cabling Recommendations

All copper Ethernet ports on RUGGEDCOM products include transient suppression
circuitry to protect against damage from electrical transients and conform with
IEC 61850-3 and IEEE 1613 Class 1 standards. This means that during a transient
electrical event, communications errors or interruptions may occur, but recovery is
automatic.
Siemens also does not recommend using copper Ethernet ports to interface with
devices in the field across distances that could produce high levels of ground
potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
1.5.1

Supported fiber optic cables

The following fiber optic cable types are supported under the stated conditions.
Cable Type Wavelength (nm) Modal Bandwidth
OM1 (62.5/125)
OM2 (50/125)
a
OM3 (50/125)
a
OM4 (50/125)
a
Laser optimized.
RUGGEDCOM RS416PF
Equipment Manual, 10/2023, C79000-G8976-1355-07
(MHz·km)
850 200
1300 500
850 500
1300 500
850 1500
1300 500
850 3500
1300 500
https://support.industry.siemens.com/cs/ww/en/
100Base-FX
—
2000
—
2000
—
2000
—
2000
Introduction
1.5 Cabling Recommendations
Distance (m)
1000Base-SX 10GBase-SR
275
—
550
—
550
—
550
—
33
—
82
—
300
—
400
—
5
