Installing Device
2.1 General Procedure
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could
invalidate specifications, test results, and agency approvals, and void the user's
authority to operate the equipment.
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
2.1

General Procedure

The general procedure for installing the device is as follows:
1.
2.
3.
4.
5.
6.
7.
10
NOTICE
NOTICE
Review the relevant certification information for any regulatory
requirements.
For more information, refer to "Approvals" (Page 41).
Unpack and inspect the device.
For more information, refer to "Unpacking the device" (Page 11).
Mount the device.
For more information, refer to "Mounting the Device" (Page 11).
Connect the failsafe alarm relay.
For more information, refer to "Connecting the Failsafe Alarm
Relay" (Page 14).
Connect power to the device and ground the device to safety Earth.
For more information, refer to "Connecting Power" (Page 15).
Connect the device to the network.
For more information, refer to "Communication Ports" (Page 25).
Configure the device.
For more information, refer to "Configuring the Device" (Page 24).
RUGGEDCOM RS416PF
Equipment Manual, 10/2023, C79000-G8976-1355-07
