3.2
OPERATION KEYS
To navigate between screens, LogBox LTE has 2 keys:
● Quick touch (less than 2 seconds):
○ Proceeds to the next screen if the current screen mnemonic is being displayed.
○ Displays the mnemonic of the current screen again if the screen information is being displayed.
● Long touch (longer than 2 seconds or held down):
○ Takes an action within the current screen.
● Both keys pressed (longer than 2 seconds or held down):
○ Takes a second action within the current screen.
3.3
NAVIGATION SCREENS
To facilitate identification of information on each screen, a mnemonic will be displayed whenever a when a key is pressed. It will remain visible for 2
seconds.
If you don't press any key during this period, the information on the current screen will be displayed. If you press the
mnemonic is being displayed, the device will advance to the next screen or return to the previous one, which will be duly specified by their
respective mnemonics.
When the device is displaying the information on a screen, just give a short press on either of the 2 keys and the mnemonic will be displayed again.
To access the desired screen, simply wait 2 seconds.
The table below shows the screens, the mnemonics, the information related to them, the description of each piece of information and the function of
the keys on each of the screens.
NOVUS AUTOMATION
. Depending on the current navigation screen, each key has 2 or more functions:
or
keys while a
7/75
