- Page 1 KIT INSTRUCTIONS 12" Pole Mount for C730/XD10 Release 1.0 5934–K020 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Mar 2017 First Issue... -
Page 4: Kit Content
12" Pole Mount for C730/XD10 Introduction This kit provides the components to install a 12" pole mount to a C730 or 10.4 X–Series Display (XD10). At least one of the following Display PIDs must be ordered for this kit: Description 5934–0419–8801 C730 No Touch, No MSR, Black, for Pole Mount 5934–0420–8801... -
Page 5: Installation Procedure
12" Pole Mount for C730 and XD10 Installation Procedure 1. Route the cables through the Integration Pole. Secure the Integration Pole to the pole mount assembly. - Page 6 12" Pole Mount for C730 and XD10 2. Route the cables through the Table Top Mount. 3. Secure the Table Top Mount to the countertop or integration tray with screws (4). Note: The screws (4) are not included in the kit. 4.
- Page 7 12" Pole Mount for C730 and XD10 7734 Cable Routing 1. Loosen the thumbscrew and Open the CableLock Cover. 2. Route the cables under the stand and up through the CableLock Cover.
- Page 8 12" Pole Mount for C730 and XD10 3. Route the cables into the cable clamps. Install the expansion blank plate and cable clamps (2) and secure with screws (2). Note: If the POS includes an expansion, install the cable clamps under the expansion and secure with screws (2).
- Page 9 12" Pole Mount for C730 and XD10 4. Connect the cables to the HDMI and 12V Powered USB ports. 5. Close and secure the CableLock Cover with the thumbscrew.
- Page 10 12" Pole Mount for C730 and XD10 7761/7745 Cable Routing 1. Pivot the display toward the back. 2. Remove the Upper Stand Cover by pivoting it away from the stand. The cover has a simple snap fit connection at the top.
- Page 11 12" Pole Mount for C730 and XD10 3. Open the CableLock Cover by loosening the thumbscrew. 4. Loosen the screw on the Terminal Cable Cover. To open, press down on the indentations in the Cable Cover to unlatch the cover and then pivot the cover open. Note: Ensure that the screw is disengaged from the threads.
- Page 12 12" Pole Mount for C730 and XD10 6. Connect the peripheral cables to the I/O Panel. 7. Close the CableLock Cover and secure with thumbscrew. 8. Secure the Upper Stand Cover. 9. Close the Terminal Cover and secure with screw (1).
- Page 13 12" Pole Mount for C730 and XD10 7702 Cable Routing Cables are routed out the opening in the Cable Cover and down through the Table-Top Stand. 1. Remove the Upper Stand Cover by pivoting it away from the stand. The cover has a simple snap fit connection at the top.
- Page 14 12" Pole Mount for C730 and XD10 3. Route the cables down through the opening in the Stand Base. 4. Close the Base Stand Cover and secure it with the Thumb Screw. 5. Replace the Upper Stand Cover.
- Page 15 12" Pole Mount for C730 and XD10 Connecting the 7702 Peripheral Cables 1. Unpack the terminal in the desired location. 2. Pivot the display toward the back.
- Page 16 12" Pole Mount for C730 and XD10 3. Open the Terminal Cable Cover. Press on the indentations in the Cable Cover to unlatch the cover and then pivot the cover open. Note: If the unit has the Cable Cover Security Bracket installed you must also loosen the two captive screws before you can open the cover.
