- Page 1 5967-K120,K121,K124, K125 Kit Instructions Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Kit Contents
Kit Title Introduction This kit provides an optional magnetic stripe reader (MSR) that mounts on the side of the 5943/5967 displays. The MSR can be installed on both the 12-inch and 15-inch models. There are four versions of the MSR. Kit Number Description 5967-K120 JIS 3-Track USB (Beige) -
Page 4: Installation Procedures
Kit Title Installation Procedures 1. Lay the display face down on a flat surface. 2. Remove the MSR Blank Cover from the display. 3. Connect the MSR Cable to the USB Extension Cable and the Ground Lug on the display. - Page 5 Kit Title 4. Install the MSR Assembly on the display (2 screws). 5. Install the MSR Rear Cabinet on the MSR Assembly (2 screws). MSR Configuration See the MSR Configuration User Guide (B005-0000-2031) for information about how to configure and reprogram the MSR.
