Summary of Contents for NCR 5968-K024
- Page 1 KIT INSTRUCTIONS Black Integration Tray Display Mount 5968-K024 Issue C...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Kit Contents
Black Integration Tray Display Mount This kit provides a display mount for integrating the 5968/5985 RealPOS X–Series Display or the 5910/5915 XL Display on various NCR POS terminals. Kit Contents... -
Page 4: Installation Procedure
Black Integration Tray Display Mount Installation Procedure 1. Secure the Display Base to the Tray Support Bracket of the Integration Tray (4 screws). - Page 5 Black Integration Tray Display Mount 2. Install the Display Swing Arm onto the Display Base. 3. Install the Display Back Plate onto the back of the display (4 screws). Note: For 5968/5985 RealPOS X–Series Displays, use the screws included with the display.
- Page 6 Black Integration Tray Display Mount 4. Route the cable through the Display Mount as shown in the exploded view below. 5. Insert the Display Back Plate into the Display Swing Arm. 6. Remove the excess slack in the cable and then install the Display Swing Arm Cover onto the Display Swing Arm.
- Page 7 Black Integration Tray Display Mount 7. Connect the cable to the display. 5968/5985 RealPOS X-Series Display 5910/5915 XL Display...
