Summary of Contents for Swiss Madison SM-BV661-C
- Page 1 Freestanding Vanity ® INSTALLATION INSTRUCTIONS w e l l m a d e f o r e v e r @SwissMadison #WellMadeForever www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com...
-
Page 2: Prior To Installation
· · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. · Read installation instructions thoroughly before installing. Be sure to use proper tools and always wear proper personal safety accessories for your protection. -
Page 3: Installation Instructions
FREESTANDING VANITY INSTALLATION INSTRUCTIONS Parts for Reference: HS26A 1. Base panel 2. Left side panel 3. Right side panel BC67 4. Front cross bar 5. Side leg connecting boards (2) 6. Front leg connecting boards (2) 7. Rear top bar BC410 8. -
Page 4: Assemble Frame
FREESTANDING VANITY INSTALLATION INSTRUCTIONS 2. Prepare Side Panels • Screw 5 cam bolts (A) into the left side panel (2). Repeat for the right side panel (3). • Insert 2 wooden dowels (C) into the left side panel (2) as shown. Repeat for the right side panel (3). •... -
Page 5: Attach Base
FREESTANDING VANITY INSTALLATION INSTRUCTIONS 4. Attach Base • Place the base panel (1) onto the cabinet frame as shown. • Insert 4 screws (E) into the base panel as shown. Using an allen key (D), secure the base into place. 5. - Page 6 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 6. Install Leg Frame • Insert 8 wooden dowels (D) into the leg frame as shown. • Attach the leg frame to the base panel (1) by sliding the wooden dowels into the base. • Insert 8 screws (I) into the leg frame as shown. Using an allen key (D), tighten each screw fully to secure the frame into place.
- Page 7 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 8. Prepare Cabinet for Installation • Insert corner brace (BC67) into the corner of the cabinet as shown. Tighten all screws to secure into place. Repeat for the last 3 corners using an additional 3 corner braces (BC67). •...
- Page 8 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 9. Secure Vanity to Wall • Select installation method from below. Please note that mounting hardware is not supplied with this vanity. Option 1: Securing to Drywall · Position cabinet against wall in desired location. · Using a pencil, make a mark on the wall through the holes in the rear top bar (7).
- Page 9 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 11. Attach Doors • Use 4 screws (G) to install 2 hinges (HS26A) to the door (9). • Use an additional 2 screws per hinge to attach the door (9) to the cabinet. If the door does not align properly, adjust the hinges according to the diagrams below.
- Page 10 The product has been subjected to improper maintenance, abuse, misuse, excessive use of chemicals, accidents, or other damages, etc. Swiss Madison makes no implication that its products comply with any local building or plumbing codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and during installation.
