- Page 1 Freestanding Vanity INSTALLATION INSTRUCTIONS w e l l m a d e f o r e v e r @SwissMadison #WellMadeForever www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com...
-
Page 2: Installation Instructions
· · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. · Read installation and maintenance instructions thoroughly before installing. Be sure to use proper tools and always wear proper personal safety accessories for your protection. - Page 3 FREESTANDING VANITY INSTALLATION INSTRUCTIONS Parts for Reference: 1. Middle Panel 2. Middle Support 3. Rear Top Bar 4. Front Top Bar 5. Rear Bottom Bar 6. Right Side Panel 7. Left Side Panel 8. Base Panel 9. Legs (2) 10. Base Support Bar 11.
- Page 4 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 1. Prepare Frame · Insert 2 wooden dowels (C) into the middle panel (1) as shown. · Insert 1 wooden dowels (C) into each end of the rear top bar (3) as shown. Repeat to the front top bar (4). ·...
-
Page 5: Assemble Frame
FREESTANDING VANITY INSTALLATION INSTRUCTIONS 3. Assemble Frame · Use 2 cam locks (B) to connect the rear top bar (3) and left side panel (7) as shown. Repeat this process to secure the front top bar (4) and the rear bottom bar (5) to the left side panel (7) as shown. -
Page 6: Attach Legs
FREESTANDING VANITY INSTALLATION INSTRUCTIONS 5. Attach Legs · Insert 2 wooden dowels (C) into each leg set (9) as shown. · Place a foam pad (F) onto the bottom of the legs sets (9) according to the diagram below. · Attach each leg set (9) to the cabinet base (8) as shown. ·... - Page 7 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 7. Attach Hinges · Remove threaded caps from bottom of screw in a hinge (E). · Align caps in designated holes of the left side door (12). Using a mallet, hammer caps into the holes, making sure that each cap is open at the top. ·...
- Page 8 FREESTANDING VANITY INSTALLATION INSTRUCTIONS 9. Optional: Secure Vanity to Wall *Hardware not included* 10. Vanity Top Installation · Install faucet and drain according to manufacturer’s installation instructions. Do not overtighten, this may cause the sink to crack. · Set the vanity top on top of the vanity base, checking the location of the p-trap and drain. ·...
- Page 9 (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations, audits, analyses, attorneys and any other professional/hired services). The Swiss Madison® warranty is a comprehensive and explicit limit of liability. All items not disclosed within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have variances regarding implied warranties;...
