EUROM Window Way-out User Manual page 43

16. Screw the clamping screw carefully to the
window frame
17. Fill up the open spaces
with the delivered isolation foam
(Figure 84, pos. 2), cut the foam if neces­
sary*.
18. Continue in chapter 'assembly air condi­
tioning hose'.
* Extra isolation foam (product
code: 875201) can be ordered via
www.eurom.nl
D. Assembly outward-swinging window rightwards
1. Make sure you have done the steps in chapter 'Assembly preparations'.
(Figure 83, pos. 1).
(Figure 84, pos. 1)
.
Figure 83.
Figure 84.
43
