EUROM Window Way-out User Manual page 41

3. Screw the top part
the bottom part
gether using the two M5 x 7 mm screws
(Figure 77, pos. 3). Make sure the width is
slightly larger than the width of the frame
of the window.
4. Place the Way-out in front of you. Make
sure the round opening is facing towards
you (Figure 78).
5. Make sure the air outlet
is pointing to the right.
6. Screw the main rail to the Way-out
using the ten 3,5 x 10 mm screws
(Figure 79, pos. 1). Make sure all screw
holes match up.
(Figure 77, pos. 1) and
(Figure 77, pos. 2) to­
(Figure 78, pos. 1)
Figure 77.
Figure 78.
Figure 79.
