Transport And Storage - EUROM Window Way-out User Manual

Figure 53.
No. Description
1 Isolation foam 1.5 m *
2 Isolation foam 1 m (2x) *
3 Anti-slip foam 40 x 220 mm
4 Anti-slip foam 40 x 55 mm (2x)
5 Anti-slip foam 30 x 40 mm (6x)
6 Sand paper with stick layer
7 M5 slide nut
8 M5 knob screw (3x)
* Extra isolation foam (product code: 875201) can be ordered via

Transport and storage

• Clean the device before storing it.
• Transport the device in an upright position.
• Store the device in an upright position, in its original packaging, in a cool, dry and dust-free
area.
30
No. Description
9 M5 x 7 mm screw (2x)
10 3.5 x 10 mm screw (10x)
11 Bracket bottom part
12 Bracket top part
13 Clamp with clamp screw
14 Main rail
15 Way-out
www.eurom.nl .
