4. Place the Way-out in front of you. Make
sure the round opening is facing towards
you (Figure 69).
5. Make sure the air outlet
is pointing to the right.
6. Screw the main rail to the Way-out
using the ten 3,5 x 10 mm screws
(Figure 70, pos. 1). Make sure all screw
holes match up.
7. Screw the bracket
the main rail in the front position using the
knob screw (Figure
you connect the knob screw to the slide
nut (Figure 71, pos. 1).
38
(Figure 69, pos. 1)
(Figure 71, pos. 3) to
71, pos. 2). Make sure
Figure 69.
Figure 70.
Figure 71.
