- Page 1 NORDcanopy HG Installation, Use and Maintenance Manual www.nordcooking.com...
-
Page 2: Table Of Contents
® NORDcanopy | HG Contents 1. In the kit 2. Frame Installation Canopy Type HG-2 3. Wall Installation Canopy Type HG-1 4. Installing Ozonator 5. Connecting Air Ducts 6. Installing supply air adjusting damper 7. Installing Cover Plate 8. Installing HFK Grease Filters, Blind Plates and Grease Collection Container 9. -
Page 3: In The Kit
® NORDcanopy | HG In the kit 1 – Supply air connection 2 – Ozonator 3 – “AirGrip” air nozzle system 4 – Blind plate for grease filter rail 5 – Grease collection container 6 – HFK grease filter (500 mm) 7 –... - Page 4 ® NORDcanopy | HG 1.1. Measurements L/2-100 L/4-100 L/4-200 L/2-200 ø100 ø125 ø315 ø100 ø315 ø125 L=1000-2500 L=2000-2500 L+50 L+50 Materjal: H.Lung 14.06.2023 Teostas Nimetus: HG-Z-1 seina Kontrollis Kinnitas Tähis: LEHT: ETS NORD AS Lihtsustatud_mud L-50 L+50 www.etsnord.com RDM-034-0124 Materjal:...
-
Page 5: Frame Installation Canopy Type
® NORDcanopy | HG Frame Installation Canopy Type HG-2 2.1. Frame Sidepanels are connected by M5×20 mm bolts. K x8 2.2. Connecting the canopy with frame First step of the connection is attaching the frame’s back wall with M5×20 mm bolts. Secondly the sides are attached with M5 self drilling screws. -
Page 6: Wall Installation Canopy Type
® NORDcanopy | HG 2.3. Installing frame interior walls Interior walls are glued to side panels interior, using the tape attached to the product. 2.4. Leveling the canopy Canopy is leveled in a way that the frame sides are reaching 25 mm above the work surface. -
Page 7: Installing Ozonator
® NORDcanopy | HG Installing Ozonator 4.1. Attaching the OZ fitting 4.2. Installing the ozonator 1 – Duct 2 – KRI control damper (not included in delivery) installed before the ozona- tor, with which +20 l/s supply air is adjusted for the ozonator. 3 –... -
Page 8: Connecting Air Ducts
® NORDcanopy | HG Connecting Air Ducts Fittings are joined using a number of rivets that have been quantified as per the size of the pipe. Ozonator air duct is connected with bellows pipe in a way that the ozonator would be removable later on. Connection of the ozonator is shown in the “Ozonator Installation and Maintenance Manual”. -
Page 9: Installing Cover Plate
® NORDcanopy | HG Installing Cover Plate Installing HFK Grease Filters, Blind Plates and Grease Collection Container Measuring and Adjusting Exhaust Airflow NORDcanopy canopies are fitted with measuring nozzles located inside the canopy. ATTN! During measurement, all HFK grease filters and blind plates must be in place and the front panel must be closed. -
Page 10: Luminaire Connection
® NORDcanopy | HG 10. Luminaire Connection NB! Performed by electrician. 11. Replacing the Luminaires Spot LED lighting is fastened with spring clips on the top surface of the canopy ceiling. For replacing the luminaire, it should be pulled downward from the canopy ceiling. -
Page 11: Kitchen Canopy Maintenance
® NORDcanopy | HG 12. Kitchen Canopy Maintenance All internal and external surfaces of the kitchen canopy, including light fixtures, are cleaned using neutral cleaning agents. Carefully rinse the surfaces after cleaning, in order to avoid harmful interactions of cleaning agents and high temperatures. DEPENDING ON ATTN! Do not use hard or abrasive detergents, chlorine or bleach when cleaning the THE FREQUENCY... - Page 12 21363 Malmö Sweden Phone: +46 40-94 68 70 Address: Förrådsvägen 5 151 58 Södertälje Sweden Phone: +46 8 550 301 40 info@etsnord.se www.etsnord.se ETS NORD International info@etsnord.com www.etsnord.com ETS NORD Ventilation Manufacturing LLC UAE Sepin Rayo sepin.rayo@etsnord.com +971 5257 02916...
