- Page 1 NORDcanopy HG Installation, Use and Maintenance Manual www.nordcooking.com...
-
Page 2: Table Of Contents
® NORDcanopy | HG Contents 1. In the kit 2. Frame Installation Canopy Type HG-2 3. Wall Installation Canopy Type HG-1 4. Installation of the Ozonator 5. Connecting Air Ducts 6. Installation of the Cover Plates 7. Installing HFK Grease Filters, Blind Plates and Grease Collection Containers 8. -
Page 3: In The Kit
® NORDcanopy | HG In the kit 1 – Supply air connection 2 – Ozonator 3 – “AirGrip” air nozzle system 4 – Blind plate for grease filter rail 5 – Grease collection container 6 – HFK grease filter (500 mm) 7 –... - Page 4 ® NORDcanopy | HG 1.1. Measurements L/2-100 L/4-100 L/4-200 L/2-200 ø100 ø125 ø315 ø315 ø100 ø125 L=1000-2500 L=2000-2500 L+50 L+50 Materjal: H.Lung 03.07.24 Teostas Nimetus: HG-Z-1 seina Kontrollis Kinnitas Tähis: LEHT: ETS NORD AS Lihtsustatud_mud L-50 L+50 www.etsnord.com RDM-034-0924 Materjal:...
-
Page 5: Frame Installation Canopy Type
® NORDcanopy | HG Frame Installation Canopy Type HG-2 2.1. Frame Sidepanels are connected by M5×20 mm bolts. K x8 2.2. Connecting the canopy with frame First step of the connection is attaching the frame’s back wall with M5×20 mm bolts. Secondly the sides are attached with M5 self drilling screws. -
Page 6: Wall Installation Canopy Type
® NORDcanopy | HG 2.3. Installing frame interior walls Interior walls are glued to side panels interior, using the tape attached to the product. 2.4. Leveling the canopy Canopy is leveled in a way that the frame sides are reaching 25 mm above the work surface. -
Page 7: Installation Of The Ozonator
® NORDcanopy | HG Installation of the Ozonator 4.1. Attaching the OZ fitting 4.2. Installing the ozonator Images are for illustrative purposes. RDM-034-0924 We reserve the right to make changes. -
Page 8: Connecting Air Ducts
® NORDcanopy | HG Connecting Air Ducts 1 – KRI damper Ø100 2 – KRI damper Ø125 3 – Duct 4 – NILM long male/female coupling Fittings are joined using a number of rivets that have been quantified as per the size of the duct, except for the NILM coupling when connecting the ozonator. -
Page 9: Installing Hfk Grease Filters, Blind Plates And Grease Collection Containers
® NORDcanopy | HG Installing HFK Grease Filters, Blind Plates and Grease Collection Containers Kinnitusserv Fixing edge Kinnitusserv Fixing edge Measuring and Adjusting Exhaust Airflow NORDcanopy canopies are fitted with measuring nozzles located inside the canopy. ATTN! During measurement, all HFK grease filters and blind plates must be in place and the front panel must be closed. -
Page 10: Luminaire Connection
® NORDcanopy | HG Luminaire Connection NB! Performed by electrician. 10. Replacing the Luminaires Spot LED lighting is fastened with spring clips on the top surface of the canopy ceiling. For replacing the luminaire, it should be pulled downward from the canopy ceiling. -
Page 11: Kitchen Canopy Maintenance
® NORDcanopy | HG 11. Kitchen Canopy Maintenance All internal and external surfaces of the kitchen canopy, including light fixtures, are cleaned using neutral cleaning agents. Carefully rinse the surfaces after cleaning, in order to avoid harmful interactions of cleaning agents and high temperatures. DEPENDING ON ATTN! Do not use hard or abrasive detergents, chlorine or bleach when cleaning the THE FREQUENCY... - Page 12 21363 Malmö Sweden Phone: +46 40-94 68 70 Address: Förrådsvägen 5 151 58 Södertälje Sweden Phone: +46 8 550 301 40 info@etsnord.se www.etsnord.se ETS NORD International info@etsnord.com www.etsnord.com ETS NORD Ventilation Manufacturing LLC UAE Sepin Rayo sepin.rayo@etsnord.com +971 5257 02916...
