Operator´s
manual
Tipper trailer
CR2260/PR2150
* the tipper trailer is shown with options

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR2260 and is the answer not in the manual?

Questions and answers

Summary of Contents for Egholm CR2260

  • Page 1 Operator´s manual Tipper trailer CR2260/PR2150 * the tipper trailer is shown with options...
  • Page 2 Reservations As it is Egholm policy to make continuous improvements, we reserve the right to alter the specifications and equipment at any time without notice. Egholm accepts no liability for errors or shortcomings in the operator’s manual.
  • Page 3: Table Of Contents

    Connect the tipper trailer - CR2260 ........
  • Page 4 General information...
  • Page 5: General Information

    General information 1.1 Safety Make sure no one is standing close to the machine while it is in use Make sure that no one is near the machine while it is in use as there is a danger of crushing. Attention As it is articulated, the rear end of the machine swings out when turning.
  • Page 6: Ec Declaration Of Conformity For Machinery

    Unless otherwise agreed in writing between the operator, customer and Egholm, Egholm is the data originator (data originator) of all data generated by the machine and attachments during use.
  • Page 7: Technical Data

    General information 1.3 Technical data Dimensions Storage dimensions Length (L)..............2150 mm Width (W) .
  • Page 8 Operator´s manual...
  • Page 9: Operator's Manual

    Operator’s manual 2.1 Assembly / Disassembly Assemble the Tipper trailer. 1. The Tipper trailer is delivered with 2 hydraulic hoses and a coupling. 2. Mount the coupling on the right hose, depending on the tractor model, and mount the hydraulic hose on the Tipper trailer.
  • Page 10: Connect The Tipper Trailer - Pr2150

    Operator’s manual - Park Ranger 2150 2.2 Connect the tipper trailer - PR2150 Connect the Tipper trailer. 1. Mount the bracket, that comes with the tipper trailer (Picture 1) 2. Connect the tipper trailer to the trailer coupling. (Picture 2) Mount the hose bracket, that comes with the 3.
  • Page 11: Start-Up - Pr2150

    Operator’s manual - Park Ranger 2150 2.3 Start-up - PR2150 1. Start the machine. 2. Use handle C, to tip and lower, the trailer. (Picture 1) A B C Use handle C to tip and lower the trailer. Operator´s Manual Tipper trailer...
  • Page 12: Connect The Tipper Trailer - Cr2260

    Operator’s manual - City Ranger 2260 2.4 Connect the tipper trailer - CR2260 Connect the Tipper trailer. 1. Connect the tipper trailer to the trailer coupling. (Picture 1) 2. Connect the hydraulic hose, to the hydraulic coupling. (Picture1) Connect trailer coupling, hydralic hose 3.
  • Page 13: Start-Up - Cr2260

    Operator’s manual - City Ranger 2260 2.5 Start-up - CR2260 1. Start the machine. 2. Use handle C sideways, to tip and lower, the trailer. (Picture 1) Operator´s Manual Tipper trailer...
  • Page 14 Service, maintenance and options Operator´s Manual Tipper trailer...
  • Page 15: Service And Maintenance

    Service and maintenance 3.1 Service and maintenance 1. Check tire pressure 1,6 bar or 24 psi. 2. Grease greasing points in the wheels. Options E90301211 Side extensions for Tipper Trailer. E90301251 Lighting for Tipper Trailer. Grease greasing points in the wheels. Operator´s Manual Tipper trailer...
  • Page 16 Conditions Operator´s Manual Tipper trailer...
  • Page 17: Conditions

    The warranty period for the materials and manufacture of this Tipper trailer is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs at no charge to the customer, including materials and working hours, in accordance with the terms and conditions listed below.
  • Page 18: Complaints

    We wish you many years of safe and satisfied use of your machine. Best regards Egholm A/S 4.3 Disposal When, in many years from now, your Tipper trailer has reached the end of its working life, it should be disposed of in a responsible manner that conforms with relevant disposal regulations.
  • Page 19: Notes

    Notes Operator´s Manual Tipper trailer...
  • Page 20 Egholm A/S Transportvej 27 7620 Lemvig, Denmark T.: +45 97 81 12 05 www.egholm.eu - info@egholm.dk...
