Operator´s
manual
Basic machine
City Ranger 2200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the City Ranger 2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Egholm City Ranger 2200

Summary of Contents for Egholm City Ranger 2200

  • Page 1 Operator´s manual Basic machine City Ranger 2200...
  • Page 2 We ask you to pay particular attention to section 1.1 Safety. The machine must only be serviced by professionals. The City Ranger 2200 is designed only for use by professionals. On delivery, the user will receive thorough training to become a competent operator.

  • Page 3: Table Of Contents

    3.3 City Ranger 2200 service and maintenance chart ....... . .

  • Page 4: Introduction

    Introduction The utility machine City Ranger 2200 The City Ranger 2200 is an outdoor utility machine with a complete range of special attachments that allows you to work outdoors, all year round. Sweeping and vacuuming in spring and autumn, mowing grass and lawn-edge cutting in the summer, sweeping snow, and spreading gravel and sand in the winter.
  • Page 5 Introduction...

  • Page 6: General Information

    Do not drive on slopes with an incline of than 10°. (Picture 3) more than 10° Make sure there is no one close to the machine when it is running. Operator’s Manual City Ranger 2200 Basic machine...
  • Page 7 Keep fingers and hands away from the A-frame as there is a danger of crushing. Avoid crushing fingers Exhaust pipe Do not touch the exhaust pipe as it becomes very hot when the machine is running. (Picture 2) Exhaust pipe Operator’s Manual City Ranger 2200 Basic machine...

  • Page 8: Ec Declaration Of Conformity

    Unless otherwise agreed in writing between the operator, customer and Egholm, Egholm is the data originator (data originator) of all data generated by the machine and attachments during use.

  • Page 9: Technical Data

    Height including roll bar ................2,000 mm Max. speed ......................21 km/h Weight Machine weight (including cab) ..............820 kg Unladen weight - Egholm 2200 with roll bar ..........760 kg Max. permitted weight: Utility machine ....................1,610 kg Machine and trailer without brakes ............2,050 kg Machine and trailer with overrunning brakes ..........
  • Page 10 Start system ............Electrical starter with glow plugs Charging system ..................Generator Charging capacity ..................2 V, 60 A Battery ..................12 V, 55 AH battery Hydraulic oil Type ..................Texaco Rando HDZ 46 Tank capacity ......................22 l Brakes ................Front-wheel drum brakes Operator’s Manual City Ranger 2200 Basic machine...
  • Page 11 General information 1.3 Technical data: - continued Turning radius Turning circle inside/outside .............00/1,640 mm Information plate Mounted on the right side of the front chassis Attention Specifications may change without notice. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 12: Steering Column

    Automatic alarm Turning the ignition key activates the alarm for three seconds, to show that the alarm is working. The alarm sound is repetitive (three seconds – beep ; thirty seconds - pause etc.) Operator’s Manual City Ranger 2200 Basic machine...
  • Page 13 4. The pre-heater light is activated when the ignition key is turned, showing that the motor pre-heater is on. When the light goes out, the ignition key can be turned all the way to start the City Ranger 2200. 5. Handbrake indicator Instrument panel – right 6.
  • Page 14 The handbrake is engaged by: Press the brake pedal all the way down. Lift the handle up. Release the brake pedal again. To disengage the handbrake: Press the brake pedal. This frees the handle. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 15: Operational Features

    General information 1.5 Operational features Work light, front Work light, rear Rotary light Windscreen wipers Washer Fan heater Air conditioning (option) Hazard lights Radio/CD player Operator’s Manual City Ranger 2200 Basic machine...

  • Page 16: Joystick Console

    B) Hold the switch (8) down, at the same time turning on the attachment. (3) and/or (5) C) Release the switch after five seconds. D) Note: If the seat sensor is activated, the PTO will stop. 12 V connector Operator’s Manual City Ranger 2200 Basic machine...
  • Page 17 Function-change switch for front attachment (attachment dependant) Weight distribution ON/OFF switch Joystick for the rear attachment and hydraulics on the back end. The functions are attachment-dependant. See the attachment operator’s manual. Adjusting weight distribution Safety cover Operator’s Manual City Ranger 2200 Basic machine...

  • Page 18: Pedals

    Advice when driving on a steep slope Users of City Ranger 2200 have reported that, from time to time, they feel that the machine does not accelerate properly when driving up an incline. The machine is designed to drive on an incline of no more than 22%.

  • Page 19: Fuses

    Empty Fuses 1. 15 Amp Rotary hazard light 2. 20 Amp Windscreen wiper/sprinkler 3. 15 Amp Fan heater, cab light 4. 15 Amp Lights front and back Diode (rectifier) Fuses – Roof Operator’s Manual City Ranger 2200 Basic machine...
  • Page 20 The left rear screen must be opened to access the main 60 Amp fuse. See Section 1.16. (Picture 1) Main switch To start the City Ranger 2200, the main switch on the right side of the machine must be set to ON. Main fuse (Pictures 2 and 3) Main switch –...

  • Page 21: Towing Fixture

    The towing fixture must be locked before the machine can drive again. Warning! Do not start the machine before the towing screw has been closed. Attention! When towing, there is no servo system. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 22: Front Attachment Frame - A-Frame

    1.11 Rear attachment frame – B-frame The B-frame locking handle must be in the open position if no attachment is attached. (Picture 2) Attaching an attachment: see the attachment operator’s manual. B-frame locking handle Operator’s Manual City Ranger 2200 Basic machine...

  • Page 23: Cab Seat - Mechanical Or Pneumatic Suspension

    Suspension (Picture 2) Higher: (Adjust by gradually pressing the handle 1) The suspension becomes firmer Lower: (Adjust by gradually releasing the handle 1) The suspension becomes softer Forwards/backwards: (Adjust using the handle 2) Operator’s Manual City Ranger 2200 Basic machine...

  • Page 24: Cab Heating

    Attention: The cab’s air conditioning filter and the water condensation drainage pipe must be serviced once a year to avoid any build-up of health-hazardous bacteria. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 25: Opening And Removing Side Screens

    1. Press the screen release button. (Picture 1) 2. Open the screen Removing the side screen The side screen can be unhooked, for easier machine servicing. (Pictures 2 and 3) Release button Removing the side screen catch Removing side cover Operator’s Manual City Ranger 2200 Basic machine...

  • Page 26: Opening The Loading Frame

    2. Pull the loading frame back all the way (until it cannot move further) The safety handle must first be lifted before the loading frame can be closed. (Picture 2) Release handle Safety lock Operator’s Manual City Ranger 2200 Basic machine...

  • Page 27: Removing The Cab/Roll Bar

    6. Tip the cabin/roll bar forwards and chock in place so that the sealing strip can be removed. (Picture 4) Loosen the 2 bolts on each side Bolts under base plate Chock, remove strip Operator’s Manual City Ranger 2200 Basic machine...
  • Page 28 10. Remove the two bolts under the base plate at Pull out the cables the front of the machine. (Picture 2) 11. Lift off the cab/roll bar (min. 2 people). (Picture 3) Bolts under base plate Lift off cab/roll bar Operator’s Manual City Ranger 2200 Basic machine...

  • Page 29: Fitting The Cab/Roll Bar

    Trim off some of the width of the strip adjacent to the holes if necessary 5. Position spacers. (Picture 4) Bolts under base plate Chock, attach strip Position spacers Operator’s Manual City Ranger 2200 Basic machine...
  • Page 30 11. Attach the two rubber strips between the base plate and cab frame (cab only). (Picture 4) 12. Attach the doors to the cab (cab only) Insert the 2 bolts on each side 3 connectors behind grate Rubber strips Operator’s Manual City Ranger 2200 Basic machine...
  • Page 31 Operator´s manual...

  • Page 32: Operator's Manual

    Topping-up – see maintenance section 3.4 Motor oil The oil level must be between the two lines on the dipstick. (Picture 3) Topping-up – see maintenance section 3.5 Hydraulic oil – sight glass Motor oil – dipstick Operator’s Manual City Ranger 2200 Basic machine...
  • Page 33 Check coolant Remove the coolant cover and check that the expansion tank is ¾ full. Attention! Never remove the water cover when the motor is hot. Diesel oil lamp Expansion tank – check coolant Operator’s Manual City Ranger 2200 Basic machine...

  • Page 34: Start, Drive And Stop

    BEFORE the motor is run at full rpm. Warning: The City Ranger 2200 is articulated – it turns sharply, immediately. Turn the steering wheel carefully. Operator’s Manual City Ranger 2200 Basic machine...
  • Page 35 3. Push the brake pedal down (Picture 1) down, lift the parking lock up (Picture 2) and release the brake pedal. (See Section 1.4) 4. Turn off the City Ranger 2200 by turning the Brake pedal Drive pedal key back to the key-release position.
  • Page 36 Service and maintenance...

  • Page 37: Service And Maintenance

    Service and maintenance 3.1 Daily maintenance Daily maintenance of the City Ranger 2200 is simple, easy and very important. Three things are required: Cleaning the water cooler, oil cooler and air filter, and cleaning of the condenser where air conditioning is fitted. (See Section 3.3) Cleaning the A-frame Keep the A-frame clean.

  • Page 38: Lubricating

    (Picture 1) Warning! Always switch off the engine before washing the machine Filter housing / air filter element 3.2 Lubricating Cables and movable parts Lubricate with a little oil approx. every 15 hours. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 39: City Ranger 2200 Service And Maintenance Chart

    Service and maintenance 3.3 City Ranger 2200 service and maintenance chart Service schedule Operation Hours Daily 1000 1200 1400 1600 1800 · · · · · · · · · Cabin filter Replace Filter housing / air filter element ·...
  • Page 40 · AC drivebelt Inspectr · AC drivebelt Replace · · AC coolant Inspect · AC drier (9) Replace · · · · · AC heat overflow Clean Basic service Full service One-off service Operator’s Manual City Ranger 2200 Basic machine...

  • Page 41: Hydraulic System

    Hydraulic oil top-up 1. Park the City Ranger 2200 on a level surface. 2. Switch the motor off. 3. Remove the oil cover and top-up with Texaco Rando HDZ 46 oil.

  • Page 42: Motor Maintenance

    Motor oil check. (Picture 1) 1. Park the City Ranger 2200 on a level surface. 2. Check the oil level before the motor starts. Check the oil level 3.
  • Page 43 10. Top-up with oil if necessary, as the oil level drops Replace the motor oil filter when the oil filter is replaced. 11. Attach the rear screen, rear wheel and bottom plate again. (Picture 3) Operator’s Manual City Ranger 2200 Basic machine...

  • Page 44: Fuel

    Warning! Never screw a bracket or other object onto the fuel tank. Removing air from the fuel system/fuel pump 1) Open the bleed fixture on the fuel filter. (Picture 1) Operator’s Manual City Ranger 2200 Basic machine...
  • Page 45 2) If hoses and hose clamps are worn, they should be immediately replaced. 3) Remove air from the fuel system, if fuel hoses have been replaced. Operator’s Manual City Ranger 2200 Basic machine...

  • Page 46: Cooler

    50 % coolant or as described on the product label. Topping-up the coolant/ Filling up with C) Carefully replace the cooler cover. coolant D) Start the Egholm 2200 and run the machine until it is sufficiently warm. E) Switch the motor off and add more coolant. (Picture 2 Important –...

  • Page 47: Air Filter

    Described in section 3.1 3.8 Air filter Cleaning the air filter: A) When the Egholm 2220 is operating in dirty and dusty conditions, open the vacuum valve every day to get rid of larger dirt and dust particles. B) Open the air filter housing.

  • Page 48: Fan V-Belt

    B) Check the V-belt for wear and tear. Tightening: Loosen the two bolts that hold the generator, and then adjust/tighten them until the V-belt is at the required tension. Remember to tighten the bolts and nuts after adjusting! Operator’s Manual City Ranger 2200 Basic machine...

  • Page 49: Adjusting The Brakes

    3. Tighten the adjustment screw through the Inspection hole inspection hole using a screwdriver. (Picture 2) 4. Tighten the adjustment screw until the brake drum begins to resist free rotation. (Picture 3) Perform this adjustment on both sides. Operator’s Manual City Ranger 2200 Basic machine...
  • Page 50 5. Check the brake pedal play. The pedal should depress 3-5 cm before it encounters resistance. (Pictures 1+2) 6. Re-fit the front wheels Check the pedal has 3-5 cm play Check the pedal has 3-5 cm play Operator’s Manual City Ranger 2200 Basic machine...
  • Page 51 Conditions...

  • Page 52: Conditions

    Conditions 4.1 Warranty The warranty period for the materials and manufacture of this City Ranger 2200 is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm A/S will carry out the necessary repairs without charge for materials and working hours in accordance with the terms and conditions listed below.

  • Page 53: Complaints

    Egholm A/S 4.3 Disposal When, many years from now, your City Ranger 2200 has reached the end of its working life, it should be disposed of in a responsible manner that conforms with relevant disposal regulations. 1. Used hydraulic oil, motor oil, diesel oil, coolant and AC coolant are to be delivered at an approved waste disposal facility or site.
  • Page 54 Wearing parts...

  • Page 55: Spare Parts

    Wearing Parts 5.1 Wearing Parts - City Ranger 2200 01100260 Tyre and wheel 90501645 Filter kit 01006580 Oil f ilter 01006500 Air filter 01002000 Hydraulic filter 01006520 Fuel filter 01007000 Cab filter 2200 01604030 AC-belt 2200 05004250 Drying filter 01006770 Fan belt 2150/2200...
  • Page 56 Wearing Parts 5.1 Wearing Parts - City Ranger 2200 05001150 Bulb, rear work light 05001180 Bulb front work light 05001010 Lightbulb, main light - 281 05001050 Lightbulb, rotating flash 05001060 Lightbulb, main light - 285 05001040 Lightbulb, main light - 286...
  • Page 57 Wearing Parts 5.1 Wearing Parts - City Ranger 2200 04501230 Hydraulic couplings rear tap, female Operator’s Manual City Ranger 2200 Basic machine...

  • Page 58: Notes

    Notes Operator’s Manual City Ranger 2200 Basic machine...
  • Page 59 Notes Operator’s Manual City Ranger 2200 Basic machine...
  • Page 60 Egholm A/S Transportvej 27 7620 Lemvig, Denmark T.: +45 97 81 12 05 www.egholm.eu - info@egholm.dk...
