9.0 Display

To show the data generated by the calculator in the display, various win-
dows are provided as loop functions that can be called up in succession to
display the system information associated with each window (e.g. energy
amounts, water volume, running days, water amounts, current tempera-
tures). The energy meter has 6 di erent display loops.
Informative Displays (Standard)
Loop Sequence
1.1
1.2
1.3
1.4
"1"
1.5
Main loop
1.6
1.7
1.8
1.9
1.1
Loop Sequence
2.1
2.2
2.3
"2"
2.4
Accounting
2.5
date loop
2.6
...
2.14
Loop Sequence
3.1
3.2
3.3
3.4
"3" 3.5
Info loop
3.6
3.7
3.8
3.9
Loop Sequence
"4" 4.1
Pulse input
4.2
loop
Loop Sequence
"5"
Only in a heat meter with cooling tariff.
Tari loop
Loop Sequence
6.1
6.2
"6"
Monthly value 6.3
loop
...
6.24
8
DEN-SMT/PL
SONOMETER™ 1100
Window 1
Accumulated energy
Volume
Accumulated energy (cooling)
Flow
Power
Forward ⁄ return temperature
Temperature di erence
Operating days
Error status
Display test
Window 1
Accounting date 1
‚Accd 1'
Accounting date 1 previous year
Accounting date 2
‚Accd 2'
Accounting date 2 previous year
Accounting date 2 previous year
Window 1
Current date
,SEC_Adr'
,Pri_Adr 1'
,Pri_Adr 2'
Installation position
,Port 1'
,Port 2'
Status integrated radio
software version
Window 1
,In1'
,In2'
Window 1 Window 2
Window 1 Window 2
,LOG' date last month
,LOG' date month 1
,LOG' date month 2
,LOG' date month 23
The various display windows comprise up to several displays that
change at intervals of 2 – 4 s. The loops in the display are numbered 1,
2, ... and 6 to help the user nd his way around quickly. The main loop
is programmed with the current data as default setting, e.g. for energy,
volume and ow rate.
Window 2
(Sequence will be shown only
in a heat meter with cooling tariff)
Error hours
Window 2
Accounting date 1 energy
Future accounting date 1
Accounting date 1
previous year energy
Accounting date 2 energy
Future accounting date 2
Accounting date 2
previous year energy
Pulse input 2
Window 2
Current time
Secondary address
Primary address 1
Primary address 2
No. of the mounted module at port 1
No. of the mounted module at port 2
(Sequence will be shown only in
meters with integrated radio)
Checksum
Window 2
Accumulated value pulse input 1
Accumulated value pulse input 2
Window 3 Window 4
Window 3 Window 4
energy volume
energy volume
energy volume
...
energy volume
VI.SH.K1.02
Window 3
Window 3
‚Accd 1A'
‚Accd 1L'
‚Accd 2A'
‚Accd 2L'
Pulse input volume 2
Window 3
Window 3
,PPI' pulse value 1
,PPI' pulse value 2
Window 5 Window 6
Window 5 Window 6
max. flow rate max. power
max. flow rate max. power
max. flow rate max. power
max. flow rate max. power
