Vista - Ii Vest & Arm Mounting; 30Mm Ring Mounting - PROAIM ST-RGDB-01 Assembly Manual


Both the rings are securely mounted to the
Docking Plate.
NOTE: 1. Repeat the same process for inserting
the 42mm ring.
2. Remove the 38mm ring first and then insert
the 42mm ring.
Vista - II Vest & Arm Mounting

Hang the Vista-II Vest & Arm
on the Docking bracket.

Hang the Allen key by inserting it into the side
holes of the Docking bracket.
NOTE: It offers the convenience of multiple
1/4" thread holes, for mounting additional
accessories like Allen keys.
Flycam Zest Pro Camera Stabilizer

30mm Ring Mounting


Loosen the screw of the 54mm ring using the
3mm Allen key and open the ring.
NOTE: To insert the 30mm Ring, first, remove
the 38mm or 48mm Ring and then insert the
30mm Ring

Insert first-half of the 30mm Ring into the
54mm Ring.
(Not included)
Setup
4
