1
ISO Dampener Mitchell Mount
(ST-ISOD-01)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is
listed below.
Castle Nut Wrench
ISO Dampener
Hard Case
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable
copyright statutes or in writing by the Publisher.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PROAIM CINEMA ST-ISOD-01
Summary of Contents for PROAIM CINEMA ST-ISOD-01
- Page 1 ISO Dampener Mitchell Mount (ST-ISOD-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below. Castle Nut Wrench ISO Dampener Hard Case...
- Page 2 Safety Hints ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO THE GEAR! DO NOT FORGET TO SECURE THE EQUIPMENT The Dampener must be carefully locked while setting-up with any equipment. NEVER LEAVE THE FASTENERS LOOSE Always tighten the locking knobs properly for giving security to camera setup. BE HIGHLY VIGILANT OF FRICTION ADJUSTMENT When you are adjusting either Roll Axis / Pan Axis, make sure that the Friction adjustment of both dampers must be same.
- Page 3 ISO Dampener and tighten Castle Ring with the help of Castle Nut Wrench. YOUR PROAIM ISO DAMPENER MITCHELL MOUNT ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts.
