ADTEK CPM-20 Operation Manual page 18

Register Name
Event Log ch 11 SP
Event Log ch 11 delay time
Event Log ch 12 Parameter SLCT
Event Log ch 12 Compare
Event Log ch 12 SP
Event Log ch 12 delay time
Event Log ch 13 Parameter SLCT
Event Log ch 13 Compare
Event Log ch 13 SP
Event Log ch 13 delay time
Event Log ch 14 Parameter SLCT
Event Log ch 14 Compare
Event Log ch 14 SP
Event Log ch 14 delay time
Event Log ch 15 Parameter SLCT
Event Log ch 15 Compare
Event Log ch 15 SP
Event Log ch 15 delay time
Event Log ch 16 Parameter SLCT
Event Log ch 16 Compare
Event Log ch 16 SP
Event Log ch 16 delay time
Event Log Clear
Address Range
0336h
According to
parameter range
0337h
0338h 0~3000
0339h 0~32
033Ah 0~2
033Bh
According to
parameter range
033Ch
033Dh 0~3000
033Eh 0~32
033Fh 0~2
0340h
According to
parameter range
0341h
0342h 0~3000
0343h 0~32
0344h 0~2
0345h
According to
parameter range
0346h
0347h 0~3000
0348h 0~32
0349h 0~2
034Ah
According to
parameter range
034Bh
034Ch 0~3000
034Dh 0~32
034Eh 0~2
034Fh
According to
parameter range
0350h
0351h 0~3000
0352h 0 or 55h
17
Description
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Clear all event logs (0:None
55h:Reset)
Default R/W
1000 R/W
0 R/W
12 R/W
0 R W /
1000 R W /
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
0 R/W
