ADTEK CPM-20 Operation Manual page 17

Register Name
Event Log ch 5 Parameter SLCT
Event Log ch 5 Compare
Event Log ch 5 SP
Event Log ch 5 delay time
Event Log ch 6 Parameter SLCT
Event Log ch 6 Compare
Event Log ch 6 SP
Event Log ch 6 delay time
Event Log ch 7 Parameter SLCT
Event Log ch 7 Compare
Event Log ch 7 SP
Event Log ch 7 delay time
Event Log ch 8 Parameter SLCT
Event Log ch 8 Compare
Event Log ch 8 SP
Event Log ch 8 delay time
Event Log ch 9 Parameter SLCT
Event Log ch 9 Compare
Event Log ch 9 SP
Event Log ch 9 delay time
Event Log ch 10 Parameter SLCT
Event Log ch 10 Compare
Event Log ch 10 SP
Event Log ch 10 delay time
Event Log ch 11 Parameter SLCT
Event Log ch 11 Compare
Address Range
0316h 0~32
0317h 0~2
0318h
According to
parameter range
0319h
031Ah 0~3000
031Bh 0~32
031Ch 0~2
031Dh
According to
parameter range
031Eh
031Fh 0~3000
0320h 0~32
0321h 0~2
0322h
According to
parameter range
0323h
0324h 0~3000
0325h 0~32
0326h 0~2
0327h
According to
parameter range
0028h
0029h 0~3000
032Ah 0~32
032Bh 0~2
032Ch
According to
parameter range
032Dh
032Eh 0~3000
032Fh 0~32
0330h 0~2
0331h
According to
parameter range
0332h
0333h 0~3000
0334h 0~32
0335h 0~2
16
Description
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Set point (High Word)
Set point (Low Word)
Delay time(x10mS)
Refer to ch1
Compare condition
0:more than(>) 1:equal(=) 2:less than(<)
Default R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
1000 R/W
0 R/W
12 R/W
0 R/W
