WATER INLET HOSE CONNECTION

• Your machine may have either a single inlet (cold) or double water inlets (cold/hot) based on
its specifications. White-capped hose should be connected to cold water inlet and red-capped
hose to hot water inlet (applicable for machines with double water inlets).
• Mount new water inlet hoses to a ¾ ˝, threaded faucet.
• If the water inlet hose is not already installed, it must be screwed to the appliance The blue
marked hose is only for cold water. Depending on the model, the hot water hose marked with
red should also be connected, for models having dual inlets. Screw by hand the inlet hose onto
the tap, tightening the nut.
• Flow of water with pressure of 0,1-1 Mpa will allow your machine to operate more efficiently.)
(0,1 Mpa pressure means that more than 8 litres of water will flow through a fully-tapped faucet
per one minute.)
• Ensure that points of contact do not leak by tapping the faucet completely after carrying
making the connections.
• Ensure that the new water inlet hoses are not bent, broken, crushed and resized.
• Fix the inlet hose to the cold water tap and to the inlet valve on the rear side of the machine.
Cold fill Inlet valve
Note: Use only the new water inlet hose coming with your machine while making water inlet
connections of your machine. Never use old, used or damaged water inlet hoses.
