5.2 Selecting the Location
Locate the mixer on a level, stable surface near a grounded electrical outlet. The surface should be clean and free of dust to ensure
that the feet grip the surface firmly. Allow sufficient clearance on all sides of the unit for proper ventilation. Position at least 30 cm
from walls, 30 cm from ceilings, and 30 cm between mixers if using multiple units.
With the power switch in the Off position, plug the power cord into a grounded receptacle.

6.0 Operating Instructions

All operating controls are located on the front panel. The power switch, located on the left side of the panel, has three positions: On,
Off, and Touch. When set to the On position, the mixer will operate continuously until the switch is moved to either the Off or Touch
position. When set to the Touch position, the mixer is activated by depressing the mixing head. When pressure is released from the
mixing head, operation will stop.
The Speed control, located on the right side of the panel, is continuously adjustable. Oscillating speed increases at a nonuniform rate
to a maximum of 3,400 rpm (3,200 rpm for 100V units and 2,800 rpm for 230V units) as the knob is turned clockwise. Before turning
on the mixer, set the speed control to the minimum.
To begin operation, move the power switch to either the Touch or On position, and turn the Speed control to the desired setting. If
the power switch is in the On position, the shaking head will begin moving immediately. If the power switch is in the Touch position,
operation will begin when an object is placed on the shaking head and slight pressure is applied to depress the head. Shaking will
cease when the object is removed and pressure released.

7.0 Maintenance

WARNING: Disconnect the Vortex Mixer from the power source before attempting any cleaning or maintenance procedures.
After each use, wipe down the mixer with a soft cloth. Do not immerse the unit or pour liquids over it as electrical shock may occur.
Clean up any spills immediately taking the proper precautions. If required, the shaking head may be removed. First, disconnect the
mixer from the power source and then slowly pull the shaking head straight up and off of the shaking post. The head may then be
cleaned with a mild detergent. Be sure the head is thoroughly dry before replacing it on the unit.
The motor and shaking mechanism in the Vortex Mixer requires no routine maintenance or lubrication. To ensure a long life for the
mixer, it should be used in a dry, non-corrosive environment.

8.0 Accessories (sold separately)

Products may not be available in all markets.
Cat. No. Description
S0200-20 Optional head, 3 inch, for processing larger numbers of tubes
S0200-21 Optional head for 24 x 1.5/2.0 mL tubes, 24 x 0.5 mL tubes, and 32 x 0.2 mL tubes (or 4 tube strips)
S0200-22 Optional head for 1 microplate or 64 x 0.2 mL tubes or 8 x 0.2 mL tube strips
S0200-23 Optional head for 8 x 15 mL and 8 x 12/13 mm diameter tubes
S0200-24 Optional head attachment for 6 x 50 mL tubes
S0200-25 Optional head for 12 x 1.5/2.0 mL tubes, held horizontally
S0200-26 Optional head for 4 x 15 mL tubes, held horizontally
S0200-27 Optional head for 2 x 50 mL tubes, held horizontally
Instructions for using accessories.
1. Turn the power Off, and rotate the speed knob to the minimum.
2. Hold the unit down, and lift the mixing head.
3. Apply the desired optional accessory, and load it in a balanced manner.
4. Turn on the unit.
5. Slowly rotate the speed knob clockwise until the desired mixing level is achieved.
NOTE: If the unit starts to move across the bench, reduce speed accordingly.
Instruction Manual | 3
