Counter Shaft - Cub Cadet Yanmar Ex32002 Part List Manual

Ex Series
REF
NO.
PART NUMBER
1 CY-1A8160-25360
2 CY-1A8160-25370
3 CY-1A8160-25390
4 CY-194150-25530
5 CY-1A8160-25650
6 CY-1A8160-25810
7 CY-198220-25830
8 CY-194515-25840
9 CY-198220-25840
10 CY-198415-25840
11 CY-1A8160-25990
12 CY-1A8160-28190
13 CY-194191-28350
14 CY-22242-000340
15 CY-24101-063074
77
FIG. 42. COUNTER SHAFT
DESCRIPTION
GEAR 27
GEAR 22
GEAR 21
WASHER 20X43X2.5
BUSH 25X30X25
COLLAR, SPLINE
NUT 16, LOWER
WASHER 35X45X3
NUT16, UPPER
WASHER 16X38X4.5
BEARING, 4T32005X
PINION 27
WASHER 30X45X2.5
CIRCLIP 34
BEARING
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
