Cub Cadet Yanmar Ex32002 Part List Manual page 25

Ex Series
REF
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
FIG. 16. ALTERNATOR
PART NUMBER DESCRIPTION
CY-129795-01900 STUD
CY-119620-77201 ALTERNATOR
CY-X9490561001 NUT
CY-119620-77380 ROTOR ASSY
CY-123501-79240 BEARING, BALL
CY-119620-79250 COVER, BEARING
CY-119620-79360 THRUST WASHER
CY-119620-77421 FLAME ASSY, DRIVE
CY-119620-79200 BALL BEARING
CY-119620-79210 PLATE
CY-119620-79220 SCREW
CY-119620-79230 BOLT, STUD
CY-119620-77440 FLAME ASSY, REAR
CY-119620-77450 COVER
CY-119620-77461 PULLEY
CY-119620-77471 NUT
CY-119620-77490 COLLAR
CY-119620-77710 REGULATOR ASSY
CY-119620-79260 HOLDER
CY-119620-79270 HOLDER, BRUSH
CY-119620-77480 BRUSH ASSY
CY-119620-79280 SPRING
CY-119620-79290 SCREW
CY-119620-79300 SCREW
CY-119620-79310 BOLT
CY-119620-79320 SCREW W/WASHER
CY-119620-79330 BOLT
CY-119620-79340 INSULATION BUSH
CY-119620-79350 NUT
CY-26306-100002 NUT
CY-129107-77330 ADJUSTER, BELT
CY-124732-77340 SPACER
CY-129972-77341 BOLT, ADJUSTING
Copyright 2007 Cub Cadet Yanmar LLC
25 Ex3200
QTY
1
1
1
1
1
1
1
1
1
1
4
2
1
1
1
1
1
1
1
1
2
2
6
1
3
2
2
1
2
1
1
1
1
